T-MOTOR F60 PRO V 2207.5 KV1950
Series: T-MOTOR Brushless motors for drones
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The F60 PRO V in the 2207.5 KV1950 version from T-MOTOR, a Chinese maker, is a racing motor for 5-inch FPV quadcopters. The type code gives a stator of 22 mm diameter and 7.5 mm height; the layout has 12 slots and 14 poles, and the housing measures 26.8 x 31.7 mm.
The motor weighs 33.9 g and its KV is 1,950. On a full 6S battery at 25.2 V that works out to about 49,000 rpm at no load. The cell count is 6S, although the product information in places gives a range of 5 to 6S. Current and power, 49.3 A and 1,216 W, are 10 s peak values. That is a very short time base: it describes a burst of throttle, not a continuous load, and cannot be compared with values that apply over 30 s or 180 s.
Four of these motors weigh about 136 g together. A ready-to-fly 5-inch quadcopter usually exceeds 250 g; from that take-off mass the operator must register, and class C0 ends. FPV flights with goggles require an observer in the open category. The small 6S batteries of racing quadcopters hold only a few watt-hours, far below the 100 Wh limit for air transport.
For racing motors the ratio of weight to thrust at part load counts, not the peak value. The ESC must support 6S and carry the 49.3 A with headroom. Wear comes from crashes: bearings take impacts, shafts bend, magnets come away from the bell. The short current peaks stress the winding insulation through heat.
Technical data
Other data
| Cell count (S) | 6Scorrect |
|---|---|
| KV (rpm per volt) | 1,950correct |
| Maximum current (A) | 49.3 Acorrect |
| Maximum power (W) | 1,216correct |
| Power rating time base (s) | 10correct |
| Stator size | 2,207.5 mmcorrect |
| Weight (g) | 33.9correct |
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
