Haulotte Compact 10 – specifications
Series: Haulotte Scissor Lift
Build year not documented · Data origin: Directory data · sources
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The Haulotte Compact 10 is an electrically driven scissor lift from the Compact series by the French manufacturer. Designed as part of the indoor-use family, this model is primarily intended for work in halls, warehouses, and interior fit-out applications. In Europe, the series uses the working height in meters for its nomenclature, defining this model as a platform with a maximum reach of over ten meters.
With a working height of 10,150 mm and a lifting capacity of 450 kg, the machine provides access to higher ceiling areas while adhering to strict load limits. The empty weight of 2,330 kg combined with a compact width of 1,200 mm allows transport through standard doorways. A ground clearance of 130 mm and solid, non-marking tires in size 15 x 5 x 2 ensure safe movement on sensitive indoor floors without leaving residues. The maximum speed of 3.5 km/h and a turning radius of 2,500 mm support maneuverability in confined spaces. Power is supplied by four batteries with a capacity of 250 Ah at a system voltage of 24 V.
Within the internal ranking of the series, the Compact 10 ranks 25th out of 39 recorded models in terms of empty weight. The next smaller model is the Compact 10 N with a weight of 2,160 kg, while the next larger model, the Compact 3347E, is classified at 2,479.3 kg. The weight of the Compact 10 is practically identical to that of the Compact 2747E. The entire series ranges in empty weight from 1,270.1 kg to 7,490 kg.
Haulotte scissor lifts Compact, Optimum, H SX and HS RT – electric for the hall, diesel for the site: the number logic by metres and by feet/inches, 1.3 to 7.5 t
Haulotte of L'Horme near Saint-Étienne is Europe's largest maker of aerial work platforms and number three worldwide behind JLG and Genie; scissor lifts are the company's volume product. The register shows four families: Compact and Optimum are the electric scissor lifts for halls, warehouses and interior fit-out, H SX and HS RT the diesel rough-terrain lifts for construction sites. The numbers follow two conventions: in Europe the number gives the working height in metres – Compact 8, 10 and 12, Optimum 6 and 8, H12SX to H18SX – in the USA platform height in feet and platform width in inches: a Compact 2032 is 20 ft high and 32 in wide, an Optimum 1930E 19 ft and 30 in, an HS3388RT 33 ft and 88 in. Suffixes say more: E or AC for electric drive, DX for diesel four-wheel drive, RT for rough terrain, RTE for the electric rough-terrain version, N for the narrow, W for the wide platform, L for the extended version.
Read on 3 more paragraphs
The register lists 39 versions with service weights from 1,270 to 7,490 kg, lengths from 1,730 to 5,330 mm, widths from 760 to 2,286 mm and platform capacities from 230 to 565 kg; the diesel models deliver 18 to 24.5 kW.
The 760 mm wide Compact 8 fits through any standard door – that is the class electricians and drywall fitters hire; the HS5388RT at 5.3 m long with extension deck carries façade fitters and material to 16 m.
On used lifts, operating hours, battery condition on electric models (lead-acid traction batteries age by charge cycles), play in scissor pins and rails, hydraulic tightness, the function of tilt and overload sensors and a valid periodic inspection, without which no lift may be hired out or operated, are what count.
Sources: SpecCodex register, model data: Haulotte Scherenarbeitsbühnen, Haulotte (manufacturer)
Technical data
Engine
| Drive type | electriccorrect |
|---|
Dimensions and weights
| Length | 2,310 mmcorrect |
|---|---|
| Width | 1,200 mmcorrect |
| Ground clearance | 130 mmcorrect |
| Unladen weight | 2,330 kgcorrect |
| Platform length | 2,300.2 mmcorrect |
| Platform width | 1,200.1 mmcorrect |
Drivetrain and chassis
| Tyre size | 15 x 5 x 2correct |
|---|---|
| Tyre type | solid/non markingcorrect |
| Top speed | 3.5 km/hcorrect |
| Turning radius | 2,500 mmcorrect |
Working data
| Lifting capacity | 450 kgcorrect |
|---|---|
| Working height | 10,150 mmcorrect |
| Lift time | 51 scorrect |
| Lowering time | 42 scorrect |
| Platform extension | 920.2 mmcorrect |
| Platform capacity | 450 kgcorrect |
Electrical data
| Battery capacity | 250 Ahcorrect |
|---|---|
| Number of batteries | 4correct |
Other data
| System voltage | 24 Vcorrect |
|---|
Used listings – figures from public listings
Between September and November 2026, speccodex recorded 9 public used-machine listings for Haulotte Compact 10 on 3 platforms. Asking prices ranged from €4,950 to €13,300 (median €5,864), years of manufacture between 2008 and 2018.
Offered mainly in Germany (88%) and Hungary (12%); shares refer to listings that state a location.
Asking prices are sellers' demands, not achieved sale prices. Basis: public listings, recorded and analysed by speccodex. As of: 15 Nov 2026. Sellers usually do not state whether prices are net or gross.
Frequently asked questions
How much does the Haulotte Compact 10 weigh?
The unladen weight is 2,330 kg.
What are the dimensions of the Haulotte Compact 10?
2,310 mm × 1,200 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
