Haulotte Compact 12 – specifications
Series: Haulotte Scissor Lift
Build year not documented · Data origin: Directory data · sources
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The Haulotte Compact 12 is an electrically driven scissor lift from the Compact family of the French manufacturer. Designed as part of the series for indoor use, this machine targets applications in halls, warehouses, and interior fit-out work. The designation follows European convention, with the number 12 indicating the achievable working height in meters. The model positions itself as a compact solution for vertical work in enclosed spaces, where emission-free drives and small dimensions are decisive factors.
With a working height of 11,750 mm, the lift enables access to higher ceiling areas or racking systems. The lifting capacity of 320 kg allows for the transport of tools and materials for one person. The dimensions of 2,310 mm in length and 1,200 mm in width, along with a turning radius of 2,500 mm, ensure good maneuverability in narrow aisles. The maximum speed of 3.5 km/h is designed for safe operation in indoor environments. The solid, non-marking tires protect sensitive floors from damage. The platform offers additional reach with an extension of 920.2 mm without changing the base width.
In the comparison of the series, the model ranks 23rd out of 39 recorded variants in terms of empty weight of 2,630 kg. It is heavier than the next smaller model, the Compact 3347E, at 2,479.3 kg, but lighter than the next larger model, the Compact 8 DX, at 3,120 kg. The total range of empty weight within the series spans from 1,270.1 kg to 7,490 kg. This classification shows that the Compact 12 lies in the mid-weight range of electric scissor lifts.
Haulotte scissor lifts Compact, Optimum, H SX and HS RT – electric for the hall, diesel for the site: the number logic by metres and by feet/inches, 1.3 to 7.5 t
Haulotte of L'Horme near Saint-Étienne is Europe's largest maker of aerial work platforms and number three worldwide behind JLG and Genie; scissor lifts are the company's volume product. The register shows four families: Compact and Optimum are the electric scissor lifts for halls, warehouses and interior fit-out, H SX and HS RT the diesel rough-terrain lifts for construction sites. The numbers follow two conventions: in Europe the number gives the working height in metres – Compact 8, 10 and 12, Optimum 6 and 8, H12SX to H18SX – in the USA platform height in feet and platform width in inches: a Compact 2032 is 20 ft high and 32 in wide, an Optimum 1930E 19 ft and 30 in, an HS3388RT 33 ft and 88 in. Suffixes say more: E or AC for electric drive, DX for diesel four-wheel drive, RT for rough terrain, RTE for the electric rough-terrain version, N for the narrow, W for the wide platform, L for the extended version.
Read on 3 more paragraphs
The register lists 39 versions with service weights from 1,270 to 7,490 kg, lengths from 1,730 to 5,330 mm, widths from 760 to 2,286 mm and platform capacities from 230 to 565 kg; the diesel models deliver 18 to 24.5 kW.
The 760 mm wide Compact 8 fits through any standard door – that is the class electricians and drywall fitters hire; the HS5388RT at 5.3 m long with extension deck carries façade fitters and material to 16 m.
On used lifts, operating hours, battery condition on electric models (lead-acid traction batteries age by charge cycles), play in scissor pins and rails, hydraulic tightness, the function of tilt and overload sensors and a valid periodic inspection, without which no lift may be hired out or operated, are what count.
Sources: SpecCodex register, model data: Haulotte Scherenarbeitsbühnen, Haulotte (manufacturer)
Technical data
Engine
| Drive type | electriccorrect |
|---|
Dimensions and weights
| Length | 2,310 mmcorrect |
|---|---|
| Width | 1,200 mmcorrect |
| Ground clearance | 130 mmcorrect |
| Unladen weight | 2,630 kgcorrect |
| Platform length | 2,300.2 mmcorrect |
| Platform width | 1,200.1 mmcorrect |
Drivetrain and chassis
| Tyre size | 15 x 5 x 2correct |
|---|---|
| Tyre type | solid/non markingcorrect |
| Top speed | 3.5 km/hcorrect |
| Turning radius | 2,500 mmcorrect |
Working data
| Lifting capacity | 320 kgcorrect |
|---|---|
| Working height | 11,750 mmcorrect |
| Lift time | 85 scorrect |
| Lowering time | 50 scorrect |
| Platform extension | 920.2 mmcorrect |
| Platform capacity | 300 kgcorrect |
Electrical data
| Battery capacity | 250 Ahcorrect |
|---|---|
| Number of batteries | 4correct |
Other data
| System voltage | 24 Vcorrect |
|---|
Area: Machines › Construction machinery
Frequently asked questions
How much does the Haulotte Compact 12 weigh?
The unladen weight is 2,630 kg.
What are the dimensions of the Haulotte Compact 12?
2,310 mm × 1,200 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
