Haulotte COMPACT 2032 E – specifications
Series: Haulotte Scissor Lift
Build year not documented · Data origin: Directory data · sources
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The Haulotte Compact 2032 E is an electric scissor lift from the Compact series by the French manufacturer. The model follows US nomenclature, where the numerical values indicate the platform height in feet and the width in inches. Designed as part of the indoor-use family, this aerial work platform is primarily intended for applications in halls, warehouses, and interior fit-out work. The design is based on an electric drive system with an onboard voltage of 24 V, enabling emission-free operation in enclosed spaces.
Technically, the unit features a platform length of 2,311.4 mm and a width of 812.8 mm. An integrated platform extension of 914.4 mm extends the reach for work in hard-to-access areas. The platform load capacity is 349.3 kg, allowing the transport of tools and materials for one or two persons. With a maximum speed of 3.4 km/h and a turning radius of 2,160 mm, maneuvering in narrow aisles is possible. The ground clearance of 127 mm and tire size of 15x5 mm are designed for smooth, solid surfaces. The lift time of 26 s and the lowering time of 37 s determine the cycle time for recurring lifting operations.
In the comparison of the series, the empty weight of 1,655.2 kg ranks 33rd out of 39 models with specified data. The next smaller model is the Optimum 1930E at 1,420.2 kg, while the next larger model, the Compact 8, has a weight of 1,730 kg. The weight is practically identical to that of the COMPACT 2632 E. The range of the series spans from 1,270.1 to 7,490 kg. This classification shows that the model lies in the lower to mid-weight range of electric scissor lifts and is suitable for applications where moderate self-weight and compact dimensions are the primary considerations.
Haulotte scissor lifts Compact, Optimum, H SX and HS RT – electric for the hall, diesel for the site: the number logic by metres and by feet/inches, 1.3 to 7.5 t
Haulotte of L'Horme near Saint-Étienne is Europe's largest maker of aerial work platforms and number three worldwide behind JLG and Genie; scissor lifts are the company's volume product. The register shows four families: Compact and Optimum are the electric scissor lifts for halls, warehouses and interior fit-out, H SX and HS RT the diesel rough-terrain lifts for construction sites. The numbers follow two conventions: in Europe the number gives the working height in metres – Compact 8, 10 and 12, Optimum 6 and 8, H12SX to H18SX – in the USA platform height in feet and platform width in inches: a Compact 2032 is 20 ft high and 32 in wide, an Optimum 1930E 19 ft and 30 in, an HS3388RT 33 ft and 88 in. Suffixes say more: E or AC for electric drive, DX for diesel four-wheel drive, RT for rough terrain, RTE for the electric rough-terrain version, N for the narrow, W for the wide platform, L for the extended version.
Read on 3 more paragraphs
The register lists 39 versions with service weights from 1,270 to 7,490 kg, lengths from 1,730 to 5,330 mm, widths from 760 to 2,286 mm and platform capacities from 230 to 565 kg; the diesel models deliver 18 to 24.5 kW.
The 760 mm wide Compact 8 fits through any standard door – that is the class electricians and drywall fitters hire; the HS5388RT at 5.3 m long with extension deck carries façade fitters and material to 16 m.
On used lifts, operating hours, battery condition on electric models (lead-acid traction batteries age by charge cycles), play in scissor pins and rails, hydraulic tightness, the function of tilt and overload sensors and a valid periodic inspection, without which no lift may be hired out or operated, are what count.
Sources: SpecCodex register, model data: Haulotte Scherenarbeitsbühnen, Haulotte (manufacturer)
Technical data
Dimensions and weights
| Length | 2,500 mmcorrect |
|---|---|
| Width | 850 mmcorrect |
| Ground clearance | 127 mmcorrect |
| Unladen weight | 1,655.2 kgcorrect |
| Platform length | 2,311.4 mmcorrect |
| Platform width | 812.8 mmcorrect |
Drivetrain and chassis
| Tyre size | 15x5correct |
|---|---|
| Top speed | 3.4 km/hcorrect |
| Turning radius | 2,160 mmcorrect |
Working data
| Hydraulic oil capacity | 26.9 lcorrect |
|---|---|
| Lift time | 26 scorrect |
| Lowering time | 37 scorrect |
| Platform extension | 914.4 mmcorrect |
| Platform capacity | 349.3 kgcorrect |
| Gradeability | 23 %correct |
Electrical data
| Battery capacity | 225 Ahcorrect |
|---|
Other data
| System voltage | 24 Vcorrect |
|---|
Frequently asked questions
How much does the Haulotte COMPACT 2032 E weigh?
The unladen weight is 1,655 kg.
What are the dimensions of the Haulotte COMPACT 2032 E?
2,500 mm × 850 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
