LS XR3037H
Built: 2013 · Series: Other models
More machines from model year 2013
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
LS – other models: South Korean tractors outside the named ranges, from G3033H to XJ20, 17 to 290 kW, Mitsubishi, LS, Iveco/FPT and Shibaura engines
This page gathers LS tractors outside the named ranges, from the compact G, I and J models through the mid-range K, MT, P, PS, R and U series to the XG and XJ types and the powerful N60 Neo series. LS Tractor is the agricultural machinery arm of the South Korean LS Group (formerly LS Mtron) and sells its tractors through the LS Tractor USA subsidiary in North America as well as through importers in Europe. Engines come mainly from Mitsubishi, alongside the in-house LS brand and Iveco/FPT and Shibaura in the smaller classes.
Read on 3 more paragraphs
The register lists 84 versions here with 17 to 290 kW from three- and four-cylinder engines, lift capacities of 820 to 1,850 kg and rated speeds of 2,500 to 2,600 rpm.
Spanning from the small yard tractor to the large field tractor at around 290 kW, LS covers a broad market segment and competes, depending on class, with Kubota and Kioti in the compact range and with European and American brands at the top end; the R, U and P model prefixes each form separate ranges for yard, municipal and field work.
When buying used, identifying the fitted engine comes first, since parts supply differs for Mitsubishi, LS, Iveco/FPT and Shibaura units; also important are the condition of the gearbox and hydraulics, rust on wings and cab, the tightness of the front hitch hydraulics, and, on the larger turbocharged models, the condition of the turbocharger and intercooler.
Sources: SpecCodex register, model data: LS (weitere Modelle)
Technical data
Engine
| Engine make | Shibauracorrect |
|---|---|
| Engine model | N843T-Fcorrect |
| Fuel | dieselcorrect |
| Power | 36.5 hp (28 kW)correct |
| Rated speed | 2,600 rpmcorrect |
| Cylinders | 3correct |
| Displacement | 91.3 cu incorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 120 in (3,048 mm)correct |
|---|---|
| Width | 57.4 in (1,458 mm)correct |
| Height | 87.7 in (2227.6 mm)correct |
| Wheelbase | 65.9 in (1673.9 mm)correct |
| Unladen weight | 3567 lbs (1,618 kg)correct |
Drivetrain and chassis
| Drive | selectable four-wheel drivecorrect |
|---|---|
| Gearbox | hydrostatic transmissioncorrect |
| Forward gears | 2correct |
Working data
| Lifting capacity | 820 kgcorrect |
|---|---|
| Lifting capacity | 1808 lbs (820.1 kg)correct |
| Fuel tank capacity | 12.4 galcorrect |
Origin and approval
| Plant | South Koreacorrect |
|---|
Other data
| Linkage category | Cat Icorrect |
|---|---|
| PTO speed | 540/2000correct |
Frequently asked questions
How much power does the LS XR3037H have?
The LS XR3037H delivers 36.5 hp.
What engine does the LS XR3037H have?
3 cylinders, Diesel.
How much does the rear linkage of the LS XR3037H lift?
The rear linkage lifts 820 kg.
When was the LS XR3037H built?
Production years: 2013.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
