Terex GS4047 – specifications

Series: Terex Scissor Lift

Build year not documented · Data origin: Directory data · sources

Source: terex.com

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The GS4047 is an electric scissor lift from the Terex Scissor Lift series, technically based on Genie engineering. The model designation follows the American convention, where the digits indicate the platform height in feet and the width in inches. As a pure indoor lift without additional suffixes, it is designed for use on smooth, solid indoor floors. With a length of 2,480 mm and a width of 1,190 mm, the machine remains compact enough for narrow aisles in warehouses or production facilities. The empty weight of 3,260 kg requires appropriate vehicle load capacity during transport to ensure stability during loading.

The platform offers sufficient standing area for two persons and tools, with a length of 2,260.1 mm and a width of 1,160 mm. A load capacity of 249 kg allows handling of heavy components or materials directly on the work surface. The drive system uses four batteries with a total capacity of 300 Ah at a system voltage of 24 V, enabling emission-free work in enclosed spaces. The maximum speed of 3.2 km/h ensures safe positioning, while the gradeability of 25% allows overcoming ramps or slight unevenness. The solid, non-marking tires in size 15 x 5 protect sensitive floor coverings from abrasion and stains.

In comparison within the series, the GS4047 ranks eleventh out of 21 models with its empty weight of 3,260 kg. The next smaller model, GS2646AV, weighs 2,370 kg, while the next larger model, GS3369DC, weighs 3,480 kg. In terms of weight, the GS4047 is practically identical to the GS2669RT model. The entire series spans a weight range from 1,168 to 7,515 kg, positioning the GS4047 in the mid-segment of electric indoor lifts. This classification highlights its suitability for standard tasks in indoor assembly and maintenance, where a balanced ratio between platform size and total weight is required.

Terex scissor lifts GS1530 to GS5390RT – Genie lifts under the Terex name: the number as platform height in feet and width in inches, RT for rough terrain, DC for electric rough-terrain lifts, 1.2 to 7.5 t

The scissor lifts under the Terex name are Genie designs: since Terex took over the aerial-platform maker Genie of Redmond near Seattle in 2002, the lifts have run worldwide under the Genie brand, but in some markets and rental fleets also with a Terex badge – the GS types in the register are identical to the Genie GS. The type logic follows the American convention: GS stands for Genie Scissor, the first digits give the platform height in feet, the last the platform width in inches – a GS1930 is 19 ft high and 30 in wide, a GS3246 32 ft and 46 in, a GS5390RT 53 ft and 90 in. The suffixes name drive and duty: the models without suffix are the electric indoor lifts, RT the diesel rough-terrain lifts with all-wheel drive, DC the electric rough-terrain lifts with battery drive, AV an equipment variant.

Read on 3 more paragraphs

The register lists 21 versions with service weights from 1,168 to 7,515 kg, lengths from 1,830 to 4,880 mm and widths from 760 to 2,362 mm; the rough-terrain lifts deliver 18.5 to 55.9 kW with Kubota diesels and Ford DSG-423 petrol engines, the indoor lifts run on battery.

The GS1930 – 760 mm wide, 5.8 m platform height – is, together with the JLG 1930ES, the most-hired work platform in the world; the GS5390RT with 16 m platform height is the site lift for façades and hall roofs.

On used lifts, operating hours, battery condition on electric models, play in scissor pins and rails, hydraulic tightness, the function of tilt and overload sensors and a valid periodic inspection count; parts run through the Genie network.

Sources: SpecCodex register, model data: Terex Scherenbühnen, Genie (Terex, Hersteller)

Technical data

Dimensions and weights

Length2,480 mmcorrect
Width1,190 mmcorrect
Ground clearance95.2 mmcorrect
Unladen weight3,260 kgcorrect
Platform length2,260.1 mmcorrect
Platform width1,160 mmcorrect

Drivetrain and chassis

Tyre size15 x 5correct
Tyre typeSolid non-markingcorrect
Top speed3.2 km/hcorrect
Turning radius2,310 mmcorrect

Working data

Hydraulic oil capacity28.8 lcorrect
Lift time71 scorrect
Lowering time41 scorrect
Platform capacity249 kgcorrect
Gradeability25 %correct

Electrical data

Battery capacity300 Ahcorrect
Number of batteries4correct

Other data

System voltage24 Vcorrect

Frequently asked questions

How much does the Terex GS4047 weigh?

The unladen weight is 3,260 kg.

What are the dimensions of the Terex GS4047?

2,480 mm × 1,190 mm.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
