Terex GS1930 – specifications

Series: Terex Scissor Lift

Build year not documented · Data origin: Directory data · sources

Source: cramo.lt

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Terex GS1930 is an electric scissor lift from the Terex Scissor Lift series. As an aerial work platform, it is primarily used for the vertical positioning of personnel and tools indoors or on smooth, level surfaces. The design follows American type logic, with the designation indicating a platform height of 19 feet and a width of 30 inches. The unit is powered by a 24-volt battery system comprising four batteries with a capacity of 225 Ah. This configuration is typical for compact mobile elevating work platforms used in halls, warehouse areas, or assembly operations.

Technically, the GS1930 impresses with its compact external dimensions of 1,830 mm in length and 760 mm in width, enabling operation in narrow aisles. The ground clearance of 60.2 mm requires a level surface to avoid collisions. With an empty weight of 1,226 kg and solid non-marking tires in size 12x4.5, the unit is suitable for sensitive floors as it leaves no abrasion marks. The maximum speed of 4 km/h and a turning radius of 1,550 mm allow for precise maneuverability in confined spaces. The platform offers sufficient standing area for one person and materials, with a length of 1,630.2 mm and a width of 740.2 mm. A platform extension of 910.1 mm increases horizontal reach. The load capacity is 227 kg. The lifting time is 16 seconds, and the lowering time is 25 seconds. The gradeability of 25% allows for overcoming ramps.

Within the series, the GS1930 ranks 20th out of 21 models in terms of empty weight. The next smaller model is the GS1530 at 1,168 kg, while the next larger model, the GS2032, has a weight of 1,621 kg. The weight range of the series spans from 1,168 to 7,515 kg. This classification shows that the GS1930 belongs to the lighter variants of the scissor lifts.

Terex scissor lifts GS1530 to GS5390RT – Genie lifts under the Terex name: the number as platform height in feet and width in inches, RT for rough terrain, DC for electric rough-terrain lifts, 1.2 to 7.5 t

The scissor lifts under the Terex name are Genie designs: since Terex took over the aerial-platform maker Genie of Redmond near Seattle in 2002, the lifts have run worldwide under the Genie brand, but in some markets and rental fleets also with a Terex badge – the GS types in the register are identical to the Genie GS. The type logic follows the American convention: GS stands for Genie Scissor, the first digits give the platform height in feet, the last the platform width in inches – a GS1930 is 19 ft high and 30 in wide, a GS3246 32 ft and 46 in, a GS5390RT 53 ft and 90 in. The suffixes name drive and duty: the models without suffix are the electric indoor lifts, RT the diesel rough-terrain lifts with all-wheel drive, DC the electric rough-terrain lifts with battery drive, AV an equipment variant.

Read on 3 more paragraphs

The register lists 21 versions with service weights from 1,168 to 7,515 kg, lengths from 1,830 to 4,880 mm and widths from 760 to 2,362 mm; the rough-terrain lifts deliver 18.5 to 55.9 kW with Kubota diesels and Ford DSG-423 petrol engines, the indoor lifts run on battery.

The GS1930 – 760 mm wide, 5.8 m platform height – is, together with the JLG 1930ES, the most-hired work platform in the world; the GS5390RT with 16 m platform height is the site lift for façades and hall roofs.

On used lifts, operating hours, battery condition on electric models, play in scissor pins and rails, hydraulic tightness, the function of tilt and overload sensors and a valid periodic inspection count; parts run through the Genie network.

Sources: SpecCodex register, model data: Terex Scherenbühnen, Genie (Terex, Hersteller)

Technical data

Dimensions and weights

Length1,830 mmcorrect
Width760 mmcorrect
Ground clearance60.2 mmcorrect
Unladen weight1,226 kgcorrect
Platform length1,630.2 mmcorrect
Platform width740.2 mmcorrect

Drivetrain and chassis

Tyre size12x4.5correct
Tyre typeSolid non-markingcorrect
Top speed4 km/hcorrect
Turning radius1,550 mmcorrect

Working data

Hydraulic oil capacity14.4 lcorrect
Lift time16 scorrect
Lowering time25 scorrect
Platform extension910.1 mmcorrect
Platform capacity227 kgcorrect
Gradeability25 %correct

Electrical data

Battery capacity225 Ahcorrect
Number of batteries4correct

Other data

System voltage24 Vcorrect

Frequently asked questions

How much does the Terex GS1930 weigh?

The unladen weight is 1,226 kg.

What are the dimensions of the Terex GS1930?

1,830 mm × 760 mm.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
