Hürlimann 4 DT 45
Built: 1939–1941 · Series: Other models
More machines from model year 1939
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Hürlimann – other models: the collective page of Swiss tractors outside the named ranges, from the early petrol-paraffin types 2 M 20 to the SAME-era XA and XB, 5.9 to 67.6 kW, petrol, paraffin and diesel
This page gathers the Hürlimann tractors the register could not assign to a named range. Hürlimann of Wil in Switzerland built one of the first series-produced diesel tractors in Europe in 1929, after the company had earlier started with petrol-paraffin systems, in which the engine was started on petrol and then switched to the cheaper paraffin – a drive principle reflected in early types on this page such as the 2 M 20 and the 4 T 26 Z. In the 1970s Hürlimann became part of the Italian SAME group, today trading as Same Deutz-Fahr (SDF); since then the brand has shared platforms and assemblies with the sister marques Same and Lamborghini Trattori, visible in the later XA, XB and XL ranges with their shared type logic of power class and equipment code.
Read on 3 more paragraphs
The register lists here 33 versions with 5.9 to 67.6 kW, or 8 to 92 hp, from one- to four-cylinders of 765 to 4,954 cm³ displacement, unladen weights from 780 to 4,700 kg, lengths from 2,200 to 3,750 mm, widths from 1,400 to 1,920 mm and speeds from 1,200 to 2,100 rpm; the engines mostly ran on petrol-paraffin systems or plain petrol, and on the newer versions also on diesel.
Hürlimann ranks among the long-established Swiss tractor brands and, with its early diesel pioneering work, was ahead of its time technologically, before the brand became one of several European tractor marques with a shared platform base within the SAME group.
On the early petrol-paraffin types, the condition of the switch-over system and the ignition, on the diesel models the state of injection pump and engine, generally the tightness of gearbox and hydraulics, and rust on sheet metal count; spares run through the Same Deutz-Fahr network and specialist Swiss Hürlimann dealers.
Sources: SpecCodex register, model data: Hürlimann (weitere Modelle), Hürlimann (Same Deutz-Fahr Group, Hersteller)
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 28 hp (20.6 kW)correct |
| Rated speed | 1,800 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 2,840 cm³correct |
| Bore | 85 mmcorrect |
| Stroke | 125 mmcorrect |
| Compression ratio | 18correct |
| Injection pressure | 180 barcorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 2,400 mmcorrect |
|---|---|
| Width | 1,500 mmcorrect |
| Height | 1,450 mmcorrect |
Drivetrain and chassis
| Drive | rear-wheel drivecorrect |
|---|---|
| Gearbox | 5V/1Rcorrect |
| Forward gears | 5correct |
| Reverse gears | 1correct |
| Top speed | 23 km/hcorrect |
Origin and approval
| Units built | 72correct |
|---|
Frequently asked questions
How much power does the Hürlimann 4 DT 45 have?
The Hürlimann 4 DT 45 delivers 28 hp.
What engine does the Hürlimann 4 DT 45 have?
4 cylinders, 2,840 cm³ displacement, Diesel.
How fast does the Hürlimann 4 DT 45 go?
Top speed is 23 km/h.
What are the dimensions of the Hürlimann 4 DT 45?
2,400 mm × 1,500 mm × 1,450 mm.
When was the Hürlimann 4 DT 45 built?
Production years: 1939–1941.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 21 individual figures for this model. They come from 2 recorded sources; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
