Hürlimann 1K8 – specifications
Built: 1929–1930 · Series: Other models
The Hürlimann 1K8 is a machine built by Hürlimann. Production: 1929–1930. The engine delivers 8 hp (5.9 kW), has 1 cylinder, with a displacement of 765 cm³. Rated speed is 1,200 rpm. The machine is 2,200 mm long, 1,500 mm wide and 1,300 mm high. The unladen weight is 780 kg. Top speed is 6 km/h. Transmission: 3V/1R. The engine is water-cooled. The fuel is petrol. The bore measures 90 mm. The stroke is 120 mm. The gearbox offers 3 forward gears. There are also 1 reverse gears. Around 140 units were built. Rated output across the Hürlimann range ranges from 8 to 145 hp; the 1K8 sits at the bottom of that range with 8 hp. Its immediate neighbours are the 1K10 above it with 10 hp. Rated output across the Hürlimann range ranges from 8 to 145 hp; here the 1K8 sits at the bottom of that range with 8 hp. 88 Hürlimann models across 6 series are on record.
Data for the version built 1929–1930 · Data origin: Reference work (Wikipedia/Wikibooks) · sources
Hürlimann – other models: the collective page of Swiss tractors outside the named ranges, from the early petrol-paraffin types 2 M 20 to the SAME-era XA and XB, 5.9 to 67.6 kW, petrol, paraffin and diesel
This page gathers the Hürlimann tractors the register could not assign to a named range. Hürlimann of Wil in Switzerland built one of the first series-produced diesel tractors in Europe in 1929, after the company had earlier started with petrol-paraffin systems, in which the engine was started on petrol and then switched to the cheaper paraffin – a drive principle reflected in early types on this page such as the 2 M 20 and the 4 T 26 Z. In the 1970s Hürlimann became part of the Italian SAME group, today trading as Same Deutz-Fahr (SDF); since then the brand has shared platforms and assemblies with the sister marques Same and Lamborghini Trattori, visible in the later XA, XB and XL ranges with their shared type logic of power class and equipment code.
Read on 3 more paragraphs
The register lists here 33 versions with 5.9 to 67.6 kW, or 8 to 92 hp, from one- to four-cylinders of 765 to 4,954 cm³ displacement, unladen weights from 780 to 4,700 kg, lengths from 2,200 to 3,750 mm, widths from 1,400 to 1,920 mm and speeds from 1,200 to 2,100 rpm; the engines mostly ran on petrol-paraffin systems or plain petrol, and on the newer versions also on diesel.
Hürlimann ranks among the long-established Swiss tractor brands and, with its early diesel pioneering work, was ahead of its time technologically, before the brand became one of several European tractor marques with a shared platform base within the SAME group.
On the early petrol-paraffin types, the condition of the switch-over system and the ignition, on the diesel models the state of injection pump and engine, generally the tightness of gearbox and hydraulics, and rust on sheet metal count; spares run through the Same Deutz-Fahr network and specialist Swiss Hürlimann dealers.
Sources: SpecCodex register, model data: Hürlimann (weitere Modelle), Hürlimann (Same Deutz-Fahr Group, Hersteller)
Technical data
Engine
| Fuel | petrolcorrect |
|---|---|
| Power | 8 hp (5.9 kW)correct |
| Rated speed | 1,200 rpmcorrect |
| Cylinders | 1correct |
| Displacement | 765 cm³correct |
| Bore | 90 mmcorrect |
| Stroke | 120 mmcorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 2,200 mmcorrect |
|---|---|
| Width | 1,500 mmcorrect |
| Height | 1,300 mmcorrect |
| Unladen weight | 780 kgcorrect |
Drivetrain and chassis
| Drive | rear-wheel drivecorrect |
|---|---|
| Gearbox | 3V/1Rcorrect |
| Forward gears | 3correct |
| Reverse gears | 1correct |
| Top speed | 6 km/hcorrect |
Origin and approval
| Units built | 140correct |
|---|
Frequently asked questions
Where this model stands
Power-to-weight ratio: 7.6 kW/t (6 kW / 0.8 t)
Power class: Compact (< 40 hp)
Stronger than 1% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
