Hürlimann 1K10 – specifications
Built: 1930–1931 · Series: Other models
The 1K10 comes from Hürlimann. Production: 1930–1931. The engine delivers 10 hp (7.5 kW), has 1 cylinder, with a displacement of 850 cm³. Rated speed is 1,200 rpm. The machine is 2,200 mm long, 1,500 mm wide and 1,300 mm high. The unladen weight is 1,200 kg. Top speed is 6.5 km/h. Transmission: 3V/1R. The engine is water-cooled. The fuel is petrol. The bore measures 95 mm. The stroke is 120 mm. The gearbox offers 3 forward gears. There are also 1 reverse gears. Around 292 units were built. Rated output across the Hürlimann range ranges from 8 to 145 hp; the 1K10 sits at the bottom of that range with 10 hp. Its immediate neighbours are the 1K8 below it with 8 hp and the 4 T 18Z above it with 18 hp. Rated output across the Hürlimann range ranges from 8 to 145 hp; here the 1K10 sits at the bottom of that range with 10 hp. 88 Hürlimann models across 6 series are on record.
Data for the version built 1930–1931 · Data origin: Reference work (Wikipedia/Wikibooks) · sources
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Hürlimann – other models: the collective page of Swiss tractors outside the named ranges, from the early petrol-paraffin types 2 M 20 to the SAME-era XA and XB, 5.9 to 67.6 kW, petrol, paraffin and diesel
This page gathers the Hürlimann tractors the register could not assign to a named range. Hürlimann of Wil in Switzerland built one of the first series-produced diesel tractors in Europe in 1929, after the company had earlier started with petrol-paraffin systems, in which the engine was started on petrol and then switched to the cheaper paraffin – a drive principle reflected in early types on this page such as the 2 M 20 and the 4 T 26 Z. In the 1970s Hürlimann became part of the Italian SAME group, today trading as Same Deutz-Fahr (SDF); since then the brand has shared platforms and assemblies with the sister marques Same and Lamborghini Trattori, visible in the later XA, XB and XL ranges with their shared type logic of power class and equipment code.
Read on 3 more paragraphs
The register lists here 33 versions with 5.9 to 67.6 kW, or 8 to 92 hp, from one- to four-cylinders of 765 to 4,954 cm³ displacement, unladen weights from 780 to 4,700 kg, lengths from 2,200 to 3,750 mm, widths from 1,400 to 1,920 mm and speeds from 1,200 to 2,100 rpm; the engines mostly ran on petrol-paraffin systems or plain petrol, and on the newer versions also on diesel.
Hürlimann ranks among the long-established Swiss tractor brands and, with its early diesel pioneering work, was ahead of its time technologically, before the brand became one of several European tractor marques with a shared platform base within the SAME group.
On the early petrol-paraffin types, the condition of the switch-over system and the ignition, on the diesel models the state of injection pump and engine, generally the tightness of gearbox and hydraulics, and rust on sheet metal count; spares run through the Same Deutz-Fahr network and specialist Swiss Hürlimann dealers.
Sources: SpecCodex register, model data: Hürlimann (weitere Modelle), Hürlimann (Same Deutz-Fahr Group, Hersteller)
Technical data
Engine
| Fuel | petrolcorrect |
|---|---|
| Power | 10 hp (7.5 kW)correct |
| Rated speed | 1,200 rpmcorrect |
| Cylinders | 1correct |
| Displacement | 850 cm³correct |
| Bore | 95 mmcorrect |
| Stroke | 120 mmcorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 2,200 mmcorrect |
|---|---|
| Width | 1,500 mmcorrect |
| Height | 1,300 mmcorrect |
| Unladen weight | 1,200 kgcorrect |
Drivetrain and chassis
| Drive | rear-wheel drivecorrect |
|---|---|
| Gearbox | 3V/1Rcorrect |
| Forward gears | 3correct |
| Reverse gears | 1correct |
| Top speed | 6.5 km/hcorrect |
Origin and approval
| Units built | 292correct |
|---|
Frequently asked questions
Where this model stands
Power-to-weight ratio: 6.2 kW/t (8 kW / 1.2 t)
Power class: Compact (< 40 hp)
Stronger than 1% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
