Grove S2668E – specifications
Series: Grove Scissor Lift
Build year not documented · Data origin: Directory data · sources
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The S2668E is an electric scissor lift from the Grove Scissor Lift series. Grove, originally a US crane manufacturer and now part of the Manitowoc Group, produces these models for indoor and outdoor applications. The S series includes both compact and rough-terrain variants, with the model designation indicating the approximate working height in feet. As a pure electric variant, the S2668E omits internal combustion engines and instead uses a battery system for drive and lifting functions.
With a tare weight of 2,835 kg and dimensions of 2,460 mm in length and 1,730 mm in width, the machine is designed for transport and use on paved surfaces. The ground clearance of 139.7 mm allows it to traverse minor unevenness, while the 16x6 solid non-marking tires leave no marks on sensitive floors. The platform offers an area of 2,290.1 mm in length and 1,520.2 mm in width, which can be extended by 910.1 mm. The load capacity of 514 kg permits the use of two persons including tools. The drive is powered by four batteries with a capacity of 350 Ah at a system voltage of 24 V. The lifting and lowering times are 50 seconds each, ensuring rapid height changes.
Within the Grove Scissor Lift series, the S2668E ranks seventh among the 14 listed models with its tare weight of 2,835 kg. The next smaller model, the S2648E, weighs 2,175 kg, while the next larger model, the S2669 2WD, is slightly heavier at 2,903 kg. The weight of the S2668E is practically identical to that of the SM3269. The entire series spans a weight range from 1,341 kg to 4,037 kg. This classification shows that the S2668E is positioned in the mid-range segment of the series, offering a balance between compactness and stability for various height-related tasks.
Grove Scissor Lift: scissor lifts from S1932E to SM3269XT with dual-fuel engines, around 14.9 kW, 1,341 to 4,037 kg weight, 1,770 to 3,910 mm length
Grove was originally an independent US crane manufacturer from Shady Grove, Pennsylvania, and now belongs to the Manitowoc group, under whose roof the scissor lift range on this page also runs. The S range (S1932E to S4088) covers electric and rough-terrain scissor lifts for indoor and outdoor working heights, while the SM range (SM2646E to SM3269XT) adds narrower versions for use in tighter aisles; the number in the type gives roughly the working height in feet. The rough-terrain models are powered by dual-fuel engines of the WG750 and DF750 type, running on petrol or LPG.
Read on 3 more paragraphs
The register lists here 14 versions with around 14.9 kW, weights from 1,341 to 4,037 kg, lengths from 1,770 to 3,910 mm and widths from 830 to 2,240 mm.
Scissor lifts such as the Grove range are used in warehouses, exhibition build-outs and on construction sites for mid-height work, where the stable, vertical platform offers advantages over articulating lifts; Grove competes here chiefly with Genie, JLG and Haulotte.
For a used purchase, check the condition of the scissor bearings and pins, the tightness of the lift hydraulics, the function of the emergency lowering and overload cut-out, tyre condition, and on the dual-fuel engines the condition of the gas system; spare parts run through the Manitowoc-Grove dealer network.
Sources: SpecCodex register, model data: Grove Scissor Lift
Technical data
Dimensions and weights
| Length | 2,460 mmcorrect |
|---|---|
| Width | 1,730 mmcorrect |
| Ground clearance | 139.7 mmcorrect |
| Unladen weight | 2,835 kgcorrect |
| Platform length | 2,290.1 mmcorrect |
| Platform width | 1,520.2 mmcorrect |
Drivetrain and chassis
| Tyre size | 16x6correct |
|---|---|
| Tyre type | Solid non-markingcorrect |
Working data
| Lift time | 50 scorrect |
|---|---|
| Lowering time | 50 scorrect |
| Platform extension | 910.1 mmcorrect |
| Platform capacity | 514 kgcorrect |
Electrical data
| Battery capacity | 350 Ahcorrect |
|---|---|
| Number of batteries | 4correct |
Other data
| System voltage | 24 Vcorrect |
|---|
Frequently asked questions
How much does the Grove S2668E weigh?
The unladen weight is 2,835 kg.
What are the dimensions of the Grove S2668E?
2,460 mm × 1,730 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
