Grove SM2646E – specifications
Series: Grove Scissor Lift
Build year not documented · Data origin: Directory data · sources
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The SM2646E is an electric scissor lift from Grove's SM series. This series expands the product range with narrower models specifically designed for use in narrow aisles. The model designation reflects the working height, indicated here by the number 2646. As part of Grove's extensive portfolio, which is now owned by the Manitowoc Group, this machine is intended for applications where compact dimensions are critical.
With a width of 1,170 mm and a length of 2,510 mm, the lift features a compact design. A turning radius of 3,400 mm enables maneuvering in confined spaces. The platform offers a surface area of 2,340.1 mm in length and 1,070.1 mm in width. An extension of 910.1 mm further increases the usable working area. The platform load capacity is 635 kg, allowing for the transport of two persons with tools. The drive system consists of a 24-volt battery pack with four batteries and a capacity of 250 Ah. The maximum travel speed is 4 km/h. The lifting time of 32 s and the lowering time of 34 s determine the cycle time during frequent height changes. Solid tires in size 16x5 ensure stable footing.
Within the series comparison, the SM2646E ranks 12th out of 14 models in terms of empty weight at 1,760 kg. The next smaller model, the S1932E, weighs 1,341 kg, while the next larger model, the SM3146E, has a weight of 1,915 kg. The mass of the SM2646E is practically identical to that of the S2032E model. The weight range of the series spans from 1,341 kg to 4,037 kg. This classification indicates that the machine lies in the lower to middle weight range of the available models.
Grove Scissor Lift: scissor lifts from S1932E to SM3269XT with dual-fuel engines, around 14.9 kW, 1,341 to 4,037 kg weight, 1,770 to 3,910 mm length
Grove was originally an independent US crane manufacturer from Shady Grove, Pennsylvania, and now belongs to the Manitowoc group, under whose roof the scissor lift range on this page also runs. The S range (S1932E to S4088) covers electric and rough-terrain scissor lifts for indoor and outdoor working heights, while the SM range (SM2646E to SM3269XT) adds narrower versions for use in tighter aisles; the number in the type gives roughly the working height in feet. The rough-terrain models are powered by dual-fuel engines of the WG750 and DF750 type, running on petrol or LPG.
Read on 3 more paragraphs
The register lists here 14 versions with around 14.9 kW, weights from 1,341 to 4,037 kg, lengths from 1,770 to 3,910 mm and widths from 830 to 2,240 mm.
Scissor lifts such as the Grove range are used in warehouses, exhibition build-outs and on construction sites for mid-height work, where the stable, vertical platform offers advantages over articulating lifts; Grove competes here chiefly with Genie, JLG and Haulotte.
For a used purchase, check the condition of the scissor bearings and pins, the tightness of the lift hydraulics, the function of the emergency lowering and overload cut-out, tyre condition, and on the dual-fuel engines the condition of the gas system; spare parts run through the Manitowoc-Grove dealer network.
Sources: SpecCodex register, model data: Grove Scissor Lift
Technical data
Dimensions and weights
| Length | 2,510 mmcorrect |
|---|---|
| Width | 1,170 mmcorrect |
| Ground clearance | 100.1 mmcorrect |
| Unladen weight | 1,760 kgcorrect |
| Platform length | 2,340.1 mmcorrect |
| Platform width | 1,070.1 mmcorrect |
Drivetrain and chassis
| Tyre size | 16x5correct |
|---|---|
| Tyre type | solid tyrescorrect |
| Top speed | 4 km/hcorrect |
| Turning radius | 3,400 mmcorrect |
Working data
| Lift time | 32 scorrect |
|---|---|
| Lowering time | 34 scorrect |
| Platform extension | 910.1 mmcorrect |
| Platform capacity | 635 kgcorrect |
Electrical data
| Battery capacity | 250 Ahcorrect |
|---|---|
| Number of batteries | 4correct |
Other data
| System voltage | 24 Vcorrect |
|---|
Frequently asked questions
How much does the Grove SM2646E weigh?
The unladen weight is 1,760 kg.
What are the dimensions of the Grove SM2646E?
2,510 mm × 1,170 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
