Grove S2032E – specifications
Series: Grove Scissor Lift
Build year not documented · Data origin: Directory data · sources
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The S2032E is an electric scissor lift from the S-series manufactured by Grove. This company is now part of the Manitowoc Group, under whose umbrella the scissor lift program is managed. The series includes models for working heights in indoor and outdoor applications, with the model designation approximately indicating the working height in feet. The S2032E is positioned as a compact work platform with a length of 2,290 mm and a width of 830 mm. These dimensions enable use in areas requiring a narrow design.
Technically, the machine is powered by an electric drive with an onboard voltage of 24 V and four batteries with a capacity of 235 Ah. The maximum speed is 4 km/h, designed for safe operation on construction sites. A turning radius of 2,000 mm allows maneuvering in confined spaces. The platform offers a load capacity of 340 kg and can be extended by 910.1 mm to increase reach. The lifting time is 31 seconds, and the lowering time is 35 seconds. The empty weight of 1,727 kg and the ground clearance of 91.4 mm are designed for stability and overcoming minor obstacles.
Within the series, the S2032E ranks 12th out of 14 models in terms of empty weight. The next smaller model is the S1932E with a weight of 1,341 kg, while the next larger model, the SM3146E, weighs 1,915 kg. The weight of the S2032E is practically equal to that of the SM2646E. The weight range of the series extends from 1,341 kg to 4,037 kg. This classification shows that the S2032E lies in the lower to middle weight range of the available scissor lifts.
Grove Scissor Lift: scissor lifts from S1932E to SM3269XT with dual-fuel engines, around 14.9 kW, 1,341 to 4,037 kg weight, 1,770 to 3,910 mm length
Grove was originally an independent US crane manufacturer from Shady Grove, Pennsylvania, and now belongs to the Manitowoc group, under whose roof the scissor lift range on this page also runs. The S range (S1932E to S4088) covers electric and rough-terrain scissor lifts for indoor and outdoor working heights, while the SM range (SM2646E to SM3269XT) adds narrower versions for use in tighter aisles; the number in the type gives roughly the working height in feet. The rough-terrain models are powered by dual-fuel engines of the WG750 and DF750 type, running on petrol or LPG.
Read on 3 more paragraphs
The register lists here 14 versions with around 14.9 kW, weights from 1,341 to 4,037 kg, lengths from 1,770 to 3,910 mm and widths from 830 to 2,240 mm.
Scissor lifts such as the Grove range are used in warehouses, exhibition build-outs and on construction sites for mid-height work, where the stable, vertical platform offers advantages over articulating lifts; Grove competes here chiefly with Genie, JLG and Haulotte.
For a used purchase, check the condition of the scissor bearings and pins, the tightness of the lift hydraulics, the function of the emergency lowering and overload cut-out, tyre condition, and on the dual-fuel engines the condition of the gas system; spare parts run through the Manitowoc-Grove dealer network.
Sources: SpecCodex register, model data: Grove Scissor Lift
Technical data
Dimensions and weights
| Length | 2,290 mmcorrect |
|---|---|
| Width | 830 mmcorrect |
| Ground clearance | 91.4 mmcorrect |
| Unladen weight | 1,727 kgcorrect |
| Platform length | 2,230.1 mmcorrect |
| Platform width | 760.2 mmcorrect |
Drivetrain and chassis
| Tyre size | 4X14correct |
|---|---|
| Top speed | 4 km/hcorrect |
| Turning radius | 2,000 mmcorrect |
Working data
| Lift time | 31 scorrect |
|---|---|
| Lowering time | 35 scorrect |
| Platform extension | 910.1 mmcorrect |
| Platform capacity | 340 kgcorrect |
Electrical data
| Battery capacity | 235 Ahcorrect |
|---|---|
| Number of batteries | 4correct |
Other data
| System voltage | 24 Vcorrect |
|---|
Frequently asked questions
How much does the Grove S2032E weigh?
The unladen weight is 1,727 kg.
What are the dimensions of the Grove S2032E?
2,290 mm × 830 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
