Volvo EC240C

Series: Volvo Hydraulic Excavator

Source: https://commons.wikimedia.org/wiki/File:Volvo_EC_240C_(owner

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Volvo Hydraulic Excavator series from Volvo includes the EC240C. The engine delivers 187.6 hp (125.3 kW), has 6 cylinders, with a displacement of 7,144.8 cm³. Torque is 870.4 Nm. Rated speed is 1,800 rpm. The unladen weight is 25,904.7 kg. Ground clearance is 472.4 mm. The tank holds 124.2 litres. Maximum torque is reached at 1,800 rpm. The pump delivers 461.8 l/min. The hydraulic tank holds 85.2 litres. Working pressure is 343.4 bar. The cooling system holds 10.2 litres. The oil fill is 8.3 litres. The electrical system runs on 24 V. The engine fitted is the D7E EBE3. The Volvo Hydraulic Excavator series covers 53 models. Rated output within it ranges from 99.4 to 534.3 hp; the EC240C sits in the lower part of that range with 187.6 hp. Its immediate neighbours are the EC240BLC below it with 182.2 hp and the EC250DL above it with 190.6 hp. 5366 Volvo models across 29 series are on record. The model is listed under Excavators & compaction. 19 verified figures from 1 source are on file.

Technical data

Engine

Engine modelD7E EBE3correct
Power187.6 hp (125.3 kW)correct
Rated speed1,800 rpmcorrect
Torque870.4correct
Speed at max. torque1,800 rpmcorrect
Cylinders6correct
Displacement7,144.8 cm³correct
AspirationTurbocharged with Intercoolercorrect
Coolant capacity10.2 lcorrect
Engine oil capacity8.3 lcorrect

Dimensions and weights

Ground clearance472.4correct
Unladen weight25,904.7 kgcorrect

Drivetrain and chassis

System voltage24 Vcorrect

Working data

Pump flow461.8 l/mincorrect
Hydraulic oil capacity85.2 lcorrect
Hydraulic pressure343.4 barcorrect
Fuel tank capacity124.2 lcorrect

Other data

Height2,990.1correct

Where this model stands

Power-to-weight ratio: 4.8 kW/t (125 kW / 25.9 t)

Stronger than 61% of the excavators & compaction in the register — out of 1,666 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Volvo EC240C have?

The Volvo EC240C delivers 188 hp.

How much does the Volvo EC240C weigh?

The unladen weight is 25,905 kg.

What engine does the Volvo EC240C have?

6 cylinders, 7,145 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
