Volvo EC140LC

Series: Volvo Hydraulic Excavator

Source: https://www.kleinanzeigen.de/s-anzeige/mercedes-benz-w126-fe

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The EC140LC from Volvo is part of the Volvo Hydraulic Excavator series. The engine delivers 108 hp (73.5 kW), has 4 cylinders, with a displacement of 3,900.1 cm³. Torque is 431 Nm. Rated speed is 2,100 rpm. The unladen weight is 13,370 kg. Ground clearance is 432.8 mm. The tank holds 260.1 litres. Maximum torque is reached at 1,600 rpm. The pump delivers 21.2 l/min. The hydraulic tank holds 235.1 litres. Working pressure is 313.8 bar. The cooling system holds 23.8 litres. The oil fill is 17.8 litres. The electrical system runs on 24 V. The engine fitted is the B3,9-C. The Volvo Hydraulic Excavator series covers 53 models. Rated output within it ranges from 99.4 to 534.3 hp; the EC140LC sits at the bottom of that range with 108 hp. Its immediate neighbours are the EC140BLCM below it with 99.4 hp and the ECR145CL above it with 108.5 hp. 5366 Volvo models across 29 series are on record. The model is listed under Excavators & compaction. 19 verified figures from 1 source are on file.

Technical data

Engine

Engine modelB3.9-Ccorrect
Power108 hp (73.5 kW)correct
Rated speed2,100 rpmcorrect
Torque431correct
Speed at max. torque1,600 rpmcorrect
Cylinders4correct
Displacement3,900.1 cm³correct
Aspirationturbochargedcorrect
Coolant capacity23.8 lcorrect
Engine oil capacity17.8 lcorrect

Dimensions and weights

Ground clearance432.8correct
Unladen weight13,370 kgcorrect

Drivetrain and chassis

System voltage24 Vcorrect

Working data

Pump flow21.2 l/mincorrect
Hydraulic oil capacity235.1 lcorrect
Hydraulic pressure313.8 barcorrect
Fuel tank capacity260.1 lcorrect

Other data

Height2,770.6correct

Where this model stands

Power-to-weight ratio: 5.5 kW/t (74 kW / 13.4 t)

Stronger than 27% of the excavators & compaction in the register — out of 1,666 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Volvo EC140LC have?

The Volvo EC140LC delivers 108 hp.

How much does the Volvo EC140LC weigh?

The unladen weight is 13,370 kg.

What engine does the Volvo EC140LC have?

4 cylinders, 3,900 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
