Volvo EC140BLCM

Series: Volvo Hydraulic Excavator

Source: https://www.technikboerse.com/gebraucht/bagger-789/volvo-124

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Volvo EC140BLCM is a model in the Volvo Hydraulic Excavator series. The engine delivers 99.4 hp (69.4 kW), has 4 cylinders, with a displacement of 3,998.4 cm³. Torque is 390.5 Nm. Rated speed is 2,100 rpm. The unladen weight is 15,150 kg. Ground clearance is 542.5 mm. The tank holds 260.1 litres. Maximum torque is reached at 1,500 rpm. The pump delivers 234.7 l/min. The hydraulic tank holds 205.2 litres. Working pressure is 343.4 bar. The cooling system holds 20.4 litres. The oil fill is 15.5 litres. The electrical system runs on 24 V. The engine fitted is the D4D EBE2. The Volvo Hydraulic Excavator series covers 53 models. Rated output within it ranges from 99.4 to 534.3 hp; the EC140BLCM sits at the bottom of that range with 99.4 hp. Its immediate neighbours are the EC140LC above it with 108 hp. 5366 Volvo models across 29 series are on record. The model is listed under Excavators & compaction. 19 verified figures from 1 source are on file.

Technical data

Engine

Engine modelD4D EBE2correct
Power99.4 hp (69.4 kW)correct
Rated speed2,100 rpmcorrect
Torque390.5correct
Speed at max. torque1,500 rpmcorrect
Cylinders4correct
Displacement3,998.4 cm³correct
Aspirationturbochargedcorrect
Coolant capacity20.4 lcorrect
Engine oil capacity15.5 lcorrect

Dimensions and weights

Ground clearance542.5correct
Unladen weight15,150 kgcorrect

Drivetrain and chassis

System voltage24 Vcorrect

Working data

Pump flow234.7 l/mincorrect
Hydraulic oil capacity205.2 lcorrect
Hydraulic pressure343.4 barcorrect
Fuel tank capacity260.1 lcorrect

Other data

Height2,962.7correct

Where this model stands

Power-to-weight ratio: 4.6 kW/t (69 kW / 15.2 t)

Stronger than 24% of the excavators & compaction in the register — out of 1,666 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Volvo EC140BLCM have?

The Volvo EC140BLCM delivers 99.4 hp.

How much does the Volvo EC140BLCM weigh?

The unladen weight is 15,150 kg.

What engine does the Volvo EC140BLCM have?

4 cylinders, 3,998 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 19 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
