Ursus 1232
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The Ursus 1232 belongs to the tractor group and is an agricultural pulling vehicle. It is equipped with a six‑cylinder engine with a displacement of 6,842 cm³ and a rated power of 117 hp (86.1 kW) at 2,200 rpm. The maximum available torque is 413 Nm. The vehicle measures 4,496 mm in length, 2,267 mm in width and 2,932 mm in height. The gearbox is configured as 16 V/8 R, providing 16 forward and 8 reverse gears. The fuel tank holds 130 L and the pump speed ranges from 540 rpm to 1,000 rpm. The lift category is Cat II/III.
The 117 hp power enables pulling heavy implements and handling demanding field work. The high torque of 413 Nm provides good pulling force at low engine speeds, which is especially advantageous for plowing and harrowing. With 16 forward and 8 reverse gears, the working speed can be flexibly adjusted to different conditions. The generous 130 L tank capacity reduces refueling stops during long operations.
The Ursus 1232 is designed for typical tasks in medium to large agricultural enterprises. It is particularly suitable for field cultivation, transport of harvests, and operation of heavy implements, where both power and torque are decisive.
Ursus — one brand, two licences, many relatives
Anyone looking at an Ursus rarely sees a purely in-house design. The brand's history is a history of licences — and that is precisely why parts are often easier to find than the production figures would suggest.
Read on 4 more paragraphs
In 1965 the Warsaw plant began building the C-4011 under a licence agreement with Zetor in Brno. At its heart sat the S-4001 engine, the Polish version of Zetor's Z-4001. That kinship runs through the ranges: the later C-360, built from 1976 and in the programme until the end of 1994, used the S-4003, the strongest engine of that family.
In 1974 a second licence followed — the British one from Massey Ferguson, together with the associated production plant. Models such as the MF 235, MF 255 and MF 265 were then built in Poland with Perkins engines and became a fixture on many farms. The higher Ursus ranges with four-digit numbers descend from this line.
One remarkable long-runner stands out: the C-325 and its revised versions C-328 and C-330 — popularly the "thirties" — plus the C-335 export version, ran without interruption for 34 years until 1993.
When buying used it is therefore worth establishing the range's ancestry first. An Ursus from the Zetor line shares engine parts with Czech machines, one from the Massey Ferguson line with British ones. That decides where to look for components.
Sources: warzywa.pl, Wiadomości Rolnicze Polska, ursus.info.pl
Technical data
Engine
| Power | 117 hp (86.1 kW)correct |
|---|---|
| Rated speed | 2,200 rpmcorrect |
| Torque | 413 Nmcorrect |
| Cylinders | 6correct |
| Displacement | 6,842 cm³correct |
Dimensions and weights
| Length | 4,496 mmcorrect |
|---|---|
| Width | 2,267 mmcorrect |
| Height | 2,932 mmcorrect |
Drivetrain and chassis
| Gearbox | 16 V/8 Rcorrect |
|---|---|
| Forward gears | 16correct |
| Reverse gears | 8correct |
Working data
| Fuel tank capacity | 130 lcorrect |
|---|
Other data
| Linkage category | Cat II/IIIcorrect |
|---|---|
| PTO speed | 540/1000 rpmcorrect |
Frequently asked questions
How much power does the Ursus 1232 have?
The Ursus 1232 delivers 117 hp.
What engine does the Ursus 1232 have?
6 cylinders, 6,842 cm³ displacement.
What are the dimensions of the Ursus 1232?
4,496 mm × 2,267 mm × 2,932 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 15 individual figures for this model. They come from 2 recorded sources; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
