Ursus 1.002 / 1.004

Built: 1984–2009 · Series: Other models

More machines from model year 1984

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The 1.002 / 1.004 comes from Ursus. Production: 1984–2009. The engine delivers 96 hp (70.6 kW), has 4 cylinders, with a displacement of 4,562 cm³. Torque is 317 Nm. Rated speed is 2,200 rpm. The machine is 3,950 mm long, 2,080 mm wide and 2,630 mm high. The unladen weight is 3,500 kg. The wheelbase measures 2,385 mm. Ground clearance is 350 mm. Top speed is 25 km/h. Transmission: 16 V/8 R. The engine is water-cooled. Tyres: front 7.50-20 ASF (A: 12.4-24 AS), rear 18.4-34 AS. The fuel is diesel. The bore measures 110 mm. The stroke is 120 mm. The compression ratio is 17:1. Maximum torque is reached at 1,600 rpm. Construction: semi-frame construction. Rated output across the Ursus range ranges from 8 to 192.6 hp; the 1.002 / 1.004 sits in the middle of that range with 96 hp. Its immediate neighbours are the 1044 below it with 90 hp and the 1134 above it with 98 hp. Rated output across the Ursus range ranges from 5.9 to 141.7 kW; here the 1.002 / 1.004 sits in the middle of that range with 70.6 kW. 221 Ursus models across 12 series are on record.

Ursus — one brand, two licences, many relatives

Anyone looking at an Ursus rarely sees a purely in-house design. The brand's history is a history of licences — and that is precisely why parts are often easier to find than the production figures would suggest.

Read on 4 more paragraphs

In 1965 the Warsaw plant began building the C-4011 under a licence agreement with Zetor in Brno. At its heart sat the S-4001 engine, the Polish version of Zetor's Z-4001. That kinship runs through the ranges: the later C-360, built from 1976 and in the programme until the end of 1994, used the S-4003, the strongest engine of that family.

In 1974 a second licence followed — the British one from Massey Ferguson, together with the associated production plant. Models such as the MF 235, MF 255 and MF 265 were then built in Poland with Perkins engines and became a fixture on many farms. The higher Ursus ranges with four-digit numbers descend from this line.

One remarkable long-runner stands out: the C-325 and its revised versions C-328 and C-330 — popularly the "thirties" — plus the C-335 export version, ran without interruption for 34 years until 1993.

When buying used it is therefore worth establishing the range's ancestry first. An Ursus from the Zetor line shares engine parts with Czech machines, one from the Massey Ferguson line with British ones. That decides where to look for components.

Sources: warzywa.pl, Wiadomości Rolnicze Polska, ursus.info.pl

Technical data

Engine

Fueldieselcorrect
Power96 hp (70.6 kW)correct
Rated speed2,200 rpmcorrect
Torque317 Nmcorrect
Speed at max. torque1,600 rpmcorrect
Cylinders4correct
Displacement4,562 cm³correct
Bore110 mmcorrect
Stroke120 mmcorrect
Compression ratio17correct
Coolingwater-cooledcorrect

Dimensions and weights

Length3,950 mmcorrect
Width2,080 mmcorrect
Height2,630 mmcorrect
Wheelbase2,385 mmcorrect
Ground clearance350 mmcorrect
Unladen weight3,500 kgcorrect

Drivetrain and chassis

Driverear- and four-wheel drivecorrect
Gearbox16 V/8 Rcorrect
Front tyres7.50-20 ASF (A: 12.4-24 AS)correct
Rear tyres18.4-34 AScorrect
Top speed25 km/hcorrect

Origin and approval

Constructionsemi-frame constructioncorrect

Where this model stands

Power-to-weight ratio: 20.2 kW/t (71 kW / 3.5 t)

Power class: Universal (40–100 hp)

Stronger than 64% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Ursus 1.002 / 1.004 have?

The Ursus 1.002 / 1.004 delivers 96 hp.

How much does the Ursus 1.002 / 1.004 weigh?

The unladen weight is 3,500 kg.

What engine does the Ursus 1.002 / 1.004 have?

4 cylinders, 4,562 cm³ displacement, Diesel.

How fast does the Ursus 1.002 / 1.004 go?

Top speed is 25 km/h.

What are the dimensions of the Ursus 1.002 / 1.004?

3,950 mm × 2,080 mm × 2,630 mm.

When was the Ursus 1.002 / 1.004 built?

Production years: 1984–2009.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
  • Shift the gearbox cold and warm — jumps only show up at temperature.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 24 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →

Other models in this series

Sources: Wikibooks Traktorenlexikon (CC BY-SA 4.0) (retrieved August 2026) · How we check the data
