Michigan L90-I

Series: Michigan Integrated Tool Carrier

Source: https://www.kleinanzeigen.de/s-anzeige/magni-landwirtschaftl

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the L90-I, Michigan offers a model from the Michigan Integrated Tool Carrier series. The engine delivers 147 hp (108.1 kW), has 6 cylinders, with a displacement of 5,881.3 cm³. Torque is 556 Nm. Rated speed is 2,200 rpm. The unladen weight is 12,550 kg. The wheelbase measures 3,002.3 mm. Ground clearance is 402.3 mm. The tank holds 200.2 litres. The gearbox has 4 forward gears. There are also 4 reverse gears. Maximum torque is reached at 1,500 rpm. The hydraulic tank holds 193.1 litres. The cooling system holds 38.2 litres. The oil fill is 15.1 litres. The electrical system runs on 24 V. The engine fitted is the 6 BT 5,9. Tyre size: 20,5-25. The Michigan Integrated Tool Carrier series covers 8 models. Rated output within it ranges from 75 to 267.7 hp; the L90-I sits in the lower part of that range with 147 hp. Its immediate neighbours are the L70 below it with 119.6 hp and the L90 above it with 158.2 hp. 30 Michigan models across 6 series are on record. The model is listed under Telehandlers. 22 verified figures from 1 source are on file.

Technical data

Engine

Engine model	6 BT 5.9correct
Power	147 hp (108.1 kW)correct
Rated speed	2,200 rpmcorrect
Torque	556correct
Speed at max. torque	1,500 rpmcorrect
Cylinders	6correct
Displacement	5,881.3 cm³correct
Aspiration	turbochargedcorrect
Coolant capacity	38.2 lcorrect
Engine oil capacity	15.1 lcorrect

Dimensions and weights

Wheelbase	3,002.3correct
Ground clearance	402.3correct
Unladen weight	12,550 kgcorrect

Drivetrain and chassis

Gearbox type	Clark C270 powershift transmissioncorrect
Forward gears	4correct
Reverse gears	4correct
Tyre size	20.5-25correct
System voltage	24 Vcorrect

Working data

Hydraulic oil capacity	193.1 lcorrect
Fuel tank capacity	200.2 lcorrect

Other data

Height	3,051correct

Where this model stands

Power-to-weight ratio: 8.6 kW/t (108 kW / 12.6 t)

Stronger than 88% of the telehandlers in the register — out of 658 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Michigan L90-I have?

The Michigan L90-I delivers 147 hp.

How much does the Michigan L90-I weigh?

The unladen weight is 12,550 kg.

What engine does the Michigan L90-I have?

6 cylinders, 5,881 cm³ displacement.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
