Michigan L50B

Series: Michigan Integrated Tool Carrier

Source: https://www.kleinanzeigen.de/s-anzeige/teleskoplader-matbro-

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Michigan L50B belongs to the Michigan Integrated Tool Carrier series. The engine delivers 97.3 hp (67.9 kW), has 4 cylinders, with a displacement of 3,998.4 cm³. Torque is 370 Nm. Rated speed is 2,200 rpm. The unladen weight is 8,101.2 kg. The wheelbase measures 2,752.3 mm. Ground clearance is 381 mm. The tank holds 170.3 litres. Maximum torque is reached at 1,400 rpm. The pump delivers 31.8 l/min. The hydraulic tank holds 106.4 litres. The cooling system holds 22.3 litres. The oil fill is 11.4 litres. The electrical system runs on 24 V. The engine fitted is the VME TD 40GA. Tyre size: 15,5R25. The Michigan Integrated Tool Carrier series covers 8 models. Rated output within it ranges from 75 to 267.7 hp; the L50B sits at the bottom of that range with 97.3 hp. Its immediate neighbours are the L50 below it with 91.2 hp and the L70 above it with 119.6 hp. 30 Michigan models across 6 series are on record. The model is listed under Telehandlers. 21 verified figures from 1 source are on file.

Technical data

Engine

Engine model	VME TD 40GAcorrect
Power	97.3 hp (67.9 kW)correct
Rated speed	2,200 rpmcorrect
Torque	370correct
Speed at max. torque	1,400 rpmcorrect
Cylinders	4correct
Displacement	3,998.4 cm³correct
Aspiration	turbochargedcorrect
Coolant capacity	22.3 lcorrect
Engine oil capacity	11.4 lcorrect

Dimensions and weights

Wheelbase	2,752.3correct
Ground clearance	381correct
Unladen weight	8,101.2 kgcorrect

Drivetrain and chassis

Gearbox type	VME power shiftcorrect
Tyre size	15.5R25correct
System voltage	24 Vcorrect

Working data

Pump flow	31.8 l/mincorrect
Hydraulic oil capacity	106.4 lcorrect
Fuel tank capacity	170.3 lcorrect

Other data

Height	3,011.4correct

Where this model stands

Power-to-weight ratio: 8.4 kW/t (68 kW / 8.1 t)

Stronger than 28% of the telehandlers in the register — out of 658 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Michigan L50B have?

The Michigan L50B delivers 97.3 hp.

How much does the Michigan L50B weigh?

The unladen weight is 8,101 kg.

What engine does the Michigan L50B have?

4 cylinders, 3,998 cm³ displacement.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
