Michigan L160

Series: Michigan Integrated Tool Carrier

Source: https://www.technikboerse.com/be/gebraucht/teleskopi-eskij-p

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Michigan L160 is a model in the Michigan Integrated Tool Carrier series. The engine delivers 267.7 hp (187.9 kW), has 6 cylinders, with a displacement of 9,602.8 cm³. Torque is 962.1 Nm. Rated speed is 2,200 rpm. The unladen weight is 22,314.5 kg. The wheelbase measures 3,550.9 mm. Ground clearance is 487.7 mm. The tank holds 340.3 litres. The gearbox has 4 forward gears. There are also 4 reverse gears. Maximum torque is reached at 1,400 rpm. The pump delivers 250.2 l/min. The hydraulic tank holds 320.2 litres. The cooling system holds 70 litres. The oil fill is 27.3 litres. The electrical system runs on 24 V. The engine fitted is the TD102GB. Tyre size: 26,5-25. The Michigan Integrated Tool Carrier series covers 8 models. Rated output within it ranges from 75 to 267.7 hp; the L160 sits at the top of that range with 267.7 hp. Its immediate neighbours are the L120 below it with 202.8 hp. 30 Michigan models across 6 series are on record. The model is listed under Telehandlers. 23 verified figures from 1 source are on file.

Technical data

Engine

Engine model	TD102GBcorrect
Power	267.7 hp (187.9 kW)correct
Rated speed	2,200 rpmcorrect
Torque	962.1correct
Speed at max. torque	1,400 rpmcorrect
Cylinders	6correct
Displacement	9,602.8 cm³correct
Aspiration	turbochargedcorrect
Coolant capacity	70 lcorrect
Engine oil capacity	27.3 lcorrect

Dimensions and weights

Wheelbase	3,550.9correct
Ground clearance	487.7correct
Unladen weight	22,314.5 kgcorrect

Drivetrain and chassis

Gearbox type	Volvo BM HT 200 automatic gearbox powershift transmissioncorrect
Forward gears	4correct
Reverse gears	4correct
Tyre size	26.5-25correct
Turning radius	7,410 mmcorrect
System voltage	24 Vcorrect

Working data

Lift height	840 mmcorrect
Pump flow	250.2 l/mincorrect
Hydraulic oil capacity	320.2 lcorrect
Fuel tank capacity	340.3 lcorrect

Other data

Cab height	3,688.1correct

Where this model stands

Power-to-weight ratio: 8.4 kW/t (188 kW / 22.3 t)

Stronger than 100% of the telehandlers in the register — out of 661 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Michigan L160 have?

The Michigan L160 delivers 268 hp.

How much does the Michigan L160 weigh?

The unladen weight is 22,314 kg.

What engine does the Michigan L160 have?

6 cylinders, 9,603 cm³ displacement.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
