Michigan L120

Series: Michigan Integrated Tool Carrier

Source: https://www.technikboerse.com/en/gebraucht/excavator-loader-

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the L120, Michigan offers a model from the Michigan Integrated Tool Carrier series. The engine delivers 202.8 hp (141.7 kW), has 6 cylinders, with a displacement of 6,702.3 cm³. Torque is 710 Nm. Rated speed is 2,200 rpm. The unladen weight is 15,508.3 kg. The wheelbase measures 3,200.4 mm. Ground clearance is 451.1 mm. The tank holds 215 litres. The gearbox has 4 forward gears. There are also 3 reverse gears. Maximum torque is reached at 1,400 rpm. The pump delivers 196.1 l/min. The hydraulic tank holds 255.1 litres. The cooling system holds 65.1 litres. The oil fill is 22.3 litres. The electrical system runs on 24 V. The engine fitted is the TD71G. Tyre size: 23,5R25. The Michigan Integrated Tool Carrier series covers 8 models. Rated output within it ranges from 75 to 267.7 hp; the L120 sits in the upper part of that range with 202.8 hp. Its immediate neighbours are the L90 below it with 158.2 hp and the L160 above it with 267.7 hp. 30 Michigan models across 6 series are on record. The model is listed under Telehandlers. 23 verified figures from 1 source are on file.

Technical data

Engine

Engine model	TD71Gcorrect
Power	202.8 hp (141.7 kW)correct
Rated speed	2,200 rpmcorrect
Torque	710correct
Speed at max. torque	1,400 rpmcorrect
Cylinders	6correct
Displacement	6,702.3 cm³correct
Aspiration	turbochargedcorrect
Coolant capacity	65.1 lcorrect
Engine oil capacity	22.3 lcorrect

Dimensions and weights

Wheelbase	3,200.4correct
Ground clearance	451.1correct
Unladen weight	15,508.3 kgcorrect

Drivetrain and chassis

Gearbox type	Volvo BM HT 131 automatic gearbox powershift transmissioncorrect
Forward gears	4correct
Reverse gears	3correct
Tyre size	23.5R25correct
System voltage	24 Vcorrect

Working data

Pump flow	196.1 l/mincorrect
Hydraulic oil capacity	255.1 lcorrect
Fuel tank capacity	215 lcorrect

Other data

Height	3,386.3correct

Where this model stands

Power-to-weight ratio: 9.1 kW/t (142 kW / 15.5 t)

Stronger than 98% of the telehandlers in the register — out of 658 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Michigan L120 have?

The Michigan L120 delivers 203 hp.

How much does the Michigan L120 weigh?

The unladen weight is 15,508 kg.

What engine does the Michigan L120 have?

6 cylinders, 6,702 cm³ displacement.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
