Michigan L70

Series: Michigan Integrated Tool Carrier

Source: https://www.technikboerse.com/en/gebraucht/telehandler-354/m
The Michigan L70 is a model in the Michigan Integrated Tool Carrier series. The engine delivers 119.6 hp (82 kW), has 4 cylinders, with a displacement of 4,473.7 cm³. Torque is 440.1 Nm. Rated speed is 2,200 rpm. The unladen weight is 9,670.6 kg. The wheelbase measures 2,840.7 mm. Ground clearance is 371.9 mm. The tank holds 185.1 litres. The gearbox has 4 forward gears. There are also 3 reverse gears. Maximum torque is reached at 1,400 rpm. The pump delivers 170.3 l/min. The hydraulic tank holds 130.2 litres. The cooling system holds 27.3 litres. The oil fill is 10.6 litres. The electrical system runs on 24 V. The engine fitted is the TD 45B. Tyre size: 17,5-25 (12PR) L-2. The Michigan Integrated Tool Carrier series covers 8 models. Rated output within it ranges from 75 to 267.7 hp; the L70 sits in the lower part of that range with 119.6 hp. Its immediate neighbours are the L50B below it with 97.3 hp and the L90-I above it with 147 hp. 30 Michigan models across 6 series are on record. The model is listed under Telehandlers. 23 verified figures from 1 source are on file.

Technical data

Engine

Engine modelTD 45Bcorrect
Power119.6 hp (82 kW)correct
Rated speed2,200 rpmcorrect
Torque440.1correct
Speed at max. torque1,400 rpmcorrect
Cylinders4correct
Displacement4,473.7 cm³correct
Aspirationturbochargedcorrect
Coolant capacity27.3 lcorrect
Engine oil capacity10.6 lcorrect

Dimensions and weights

Wheelbase2,840.7correct
Ground clearance371.9correct
Unladen weight9,670.6 kgcorrect

Drivetrain and chassis

Gearbox typeVolvo BM HT 90 automatic gearbox powershift transmissioncorrect
Forward gears4correct
Reverse gears3correct
Tyre size17.5-25 (12PR) L-2correct
System voltage24 Vcorrect

Working data

Pump flow170.3 l/mincorrect
Hydraulic oil capacity130.2 lcorrect
Fuel tank capacity185.1 lcorrect

Other data

Height2,932.2correct

Where this model stands

Power-to-weight ratio: 8.5 kW/t (82 kW / 9.7 t)

Stronger than 60% of the telehandlers in the register — out of 658 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Michigan L70 have?

The Michigan L70 delivers 120 hp.

How much does the Michigan L70 weigh?

The unladen weight is 9,671 kg.

What engine does the Michigan L70 have?

4 cylinders, 4,474 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
