Michigan L50

Series: Michigan Integrated Tool Carrier

Source: https://www.technikboerse.com/en/gebraucht/telehandler-354/m
The L50 from Michigan is part of the Michigan Integrated Tool Carrier series. The engine delivers 91.2 hp (61.1 kW), has 4 cylinders, with a displacement of 4,473.7 cm³. Torque is 315.1 Nm. Rated speed is 2,200 rpm. The unladen weight is 8,101.2 kg. The wheelbase measures 2,700.5 mm. Ground clearance is 387.1 mm. The tank holds 160.1 litres. The gearbox has 4 forward gears. There are also 3 reverse gears. Maximum torque is reached at 1,200 rpm. The pump delivers 135.1 l/min. The hydraulic tank holds 125.3 litres. The cooling system holds 27.3 litres. The oil fill is 10.6 litres. The electrical system runs on 24 V. The engine fitted is the D 45B. Tyre size: 15,5-25 (12PR) L-2. The Michigan Integrated Tool Carrier series covers 8 models. Rated output within it ranges from 75 to 267.7 hp; the L50 sits at the bottom of that range with 91.2 hp. Its immediate neighbours are the L30 below it with 75 hp and the L50B above it with 97.3 hp. 30 Michigan models across 6 series are on record. The model is listed under Telehandlers. 23 verified figures from 1 source are on file.

Technical data

Engine

Engine modelD 45Bcorrect
Power91.2 hp (61.1 kW)correct
Rated speed2,200 rpmcorrect
Torque315.1correct
Speed at max. torque1,200 rpmcorrect
Cylinders4correct
Displacement4,473.7 cm³correct
Aspirationdirect injectioncorrect
Coolant capacity27.3 lcorrect
Engine oil capacity10.6 lcorrect

Dimensions and weights

Wheelbase2,700.5correct
Ground clearance387.1correct
Unladen weight8,101.2 kgcorrect

Drivetrain and chassis

Gearbox typeVolvo BM HT90 automatic gearbox powershift transmissioncorrect
Forward gears4correct
Reverse gears3correct
Tyre size15.5-25 (12PR) L-2correct
System voltage24 Vcorrect

Working data

Pump flow135.1 l/mincorrect
Hydraulic oil capacity125.3 lcorrect
Fuel tank capacity160.1 lcorrect

Other data

Height2,941.3correct

Where this model stands

Power-to-weight ratio: 7.5 kW/t (61 kW / 8.1 t)

Stronger than 23% of the telehandlers in the register — out of 658 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Michigan L50 have?

The Michigan L50 delivers 91.2 hp.

How much does the Michigan L50 weigh?

The unladen weight is 8,101 kg.

What engine does the Michigan L50 have?

4 cylinders, 4,474 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
