Leyland 344

Built: 1969–1972 · Series: Other models

Successor: 255 →

More machines from model year 1969

Source: https://www.mascus.nl/landbouw/tractoren/leyland-253/gomjpmj

The 344 comes from Leyland. Production: 1969–1972. The engine delivers 55.8 hp (41 kW), has 4 cylinders, with a displacement of 3,402 cm³. The engine comes from Leyland. Torque is 194 Nm. Rated speed is 2,200 rpm. The machine is 3,050 mm long, 1,820 mm wide and 2,172 mm high. The unladen weight is 2,125 kg. The wheelbase measures 2,032 mm. Ground clearance is 409 mm. Top speed is 25 km/h. The tank holds 72.7 litres. Transmission: 10 V/2 R. The engine is water-cooled. Tyres: front 6.00-16 ASF, rear 11-32 AS. The model was built in England. The fuel is diesel. The bore measures 195 mm. The stroke is 120 mm. The compression ratio is 17.5:1. Maximum torque is reached at 1,350 rpm. Construction: semi-frame construction. The gearbox offers 10 forward gears. There are also 2 reverse gears. Injection pressure is 173 bar. The linkage is category I/II. It was succeeded by the Leyland 255. Rated output across the Leyland range ranges from 25.3 to 101.4 hp; the 344 sits in the middle of that range with 55.8 hp. Its immediate neighbours are the 245 below it with 47.4 hp and the 262 above it with 62.9 hp. Rated output across the Leyland range ranges from 28.5 to 100 hp; here the 344 sits in the lower part of that range with 55 hp. 134 Leyland models across 15 series are on record.

Leyland – other models: the collective page of tractors outside the named ranges, from the 154 to the 904XL and the export Panther and Tiger types, 18.6 to 75 kW, Leyland and Perkins engines

Leyland built tractors at Bathgate in Scotland as successors to the Nuffield tractors, after British Leyland was formed in 1968 from a merger of British car makers; this collective page gathers the models outside the named ranges. On many three-digit types the last two digits give the approximate power in hp, as on the 255 with around 55 hp or the 384 with around 84 hp; the Synchro suffix denotes a synchromesh gearbox, as seen on the 262 Synchro/2030. For export markets some models carried predator names such as Panther, Super Panther, Tiger and Super Jaguar.

Read on 3 more paragraphs

The register lists here 35 versions with 18.6 to 75 kW (28.5 to 100 hp) from three- to six-cylinder engines of 1,488 to 5,657 cm³, unladen weights of 1,032 to 4,042 kg, lengths of 2,780 to 3,810 mm and widths of 1,537 to 2,360 mm; powered mostly by Leyland's own engines as well as SAVA, BMC and Perkins units.

Leyland tractors in the 1970s stood for British mass production of mid-size field tractors and competed with Ford, Massey Ferguson and David Brown for the same market; after the end of the British Leyland era, production at Bathgate passed to the Marshall brand, which continued the range.

Buying used, what matters on these tractors above all is the condition of the gearbox and clutch, the tightness of the hydraulics, and rust on the wings and bonnet; since spares for the British Leyland engines are limited, it is worth checking the cylinder head and injection pump, whereas far more parts are available for the Perkins units.

Sources: SpecCodex register, model data: Leyland (weitere Modelle)

Technical data

Engine

Engine make	Leylandcorrect
Fuel	dieselcorrect
Power	55.8 hp (41 kW)correct
Rated speed	2,200 rpmcorrect
Torque	194 Nmcorrect
Speed at max. torque	1,350 rpmcorrect
Cylinders	4correct
Displacement	3,402 cm³correct
Bore	195 mmcorrect
Stroke	120 mmcorrect
Compression ratio	17.5correct
Injection pressure	173 barcorrect
Cooling	water-cooledcorrect

Dimensions and weights

Length	3,050 mmcorrect
Width	1,820 mmcorrect
Height	2,172 mmcorrect
Wheelbase	2,032 mmcorrect
Ground clearance	409 mmcorrect
Unladen weight	2,125 kgcorrect

Drivetrain and chassis

Drive	rear-wheel drivecorrect
Gearbox	10 V/2 Rcorrect
Forward gears	10correct
Reverse gears	2correct
Front tyres	6.00-16 ASFcorrect
Rear tyres	11-32 AScorrect
Top speed	25 km/hcorrect

Working data

Fuel tank capacity	72.7 lcorrect

Origin and approval

Plant	Englandcorrect
Construction	semi-frame constructioncorrect

Other data

Linkage category	Cat I/IIcorrect
Successor	Leyland 255correct

Where this model stands

Power-to-weight ratio: 19.3 kW/t (41 kW / 2.1 t)

Power class: Universal (40–100 hp)

Stronger than 38% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Leyland 344 have?

The Leyland 344 delivers 55.8 hp.

How much does the Leyland 344 weigh?

The unladen weight is 2,125 kg.

What engine does the Leyland 344 have?

4 cylinders, 3,402 cm³ displacement, Diesel.

How fast does the Leyland 344 go?

Top speed is 25 km/h.

What are the dimensions of the Leyland 344?

3,050 mm × 1,820 mm × 2,172 mm.

When was the Leyland 344 built?

Production years: 1969–1972.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
Shift the gearbox cold and warm — jumps only show up at temperature.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
