Start › Excavators & compaction › Kato › HD700VIILC

Kato HD700VIILC

Series: Kato Hydraulic Excavator

Source: https://www.lectura-specs.com/en/model/construction-machiner

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Kato HD700VIILC is a model in the Kato Hydraulic Excavator series. The engine delivers 125.1 hp (92 kW), has 6 cylinders, with a displacement of 4,948.9 cm³. Torque is 431.2 Nm. Rated speed is 2,200 rpm. The unladen weight is 19,000 kg. Ground clearance is 451.1 mm. The tank holds 320.2 litres. Maximum torque is reached at 1,700 rpm. The pump delivers 460.3 l/min. The hydraulic tank holds 280.1 litres. Working pressure is 328.2 bar. The cooling system holds 22.3 litres. The oil fill is 17 litres. The electrical system runs on 24 V. The engine fitted is the 6D31T. The Kato Hydraulic Excavator series covers 40 models. Rated output within it ranges from 83 to 319.6 hp; the HD700VIILC sits in the lower part of that range with 125.1 hp. Its immediate neighbours are the HD550VIILC below it with 100.7 hp and the HD800VII above it with 140.1 hp. 62 Kato models across 5 series are on record. The model is listed under Excavators & compaction. 19 verified figures from 1 source are on file.

Technical data

Engine

Engine model6D31Tcorrect
Power125.1 hp (92 kW)correct
Rated speed2,200 rpmcorrect
Torque431.2correct
Speed at max. torque1,700 rpmcorrect
Cylinders6correct
Displacement4,948.9 cm³correct
Aspirationturbochargedcorrect
Coolant capacity22.3 lcorrect
Engine oil capacity17 lcorrect

Dimensions and weights

Ground clearance451.1correct
Unladen weight19,000 kgcorrect

Drivetrain and chassis

System voltage24 Vcorrect

Working data

Pump flow460.3 l/mincorrect
Hydraulic oil capacity280.1 lcorrect
Hydraulic pressure328.2 barcorrect
Fuel tank capacity320.2 lcorrect

Other data

Cab height2,910.8correct

More machines with this engine (6D31T, 3)

Where this model stands

Power-to-weight ratio: 4.8 kW/t (92 kW / 19 t)

Stronger than 37% of the excavators & compaction in the register — out of 1,666 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Kato HD700VIILC have?

The Kato HD700VIILC delivers 125 hp.

How much does the Kato HD700VIILC weigh?

The unladen weight is 19,000 kg.

What engine does the Kato HD700VIILC have?

6 cylinders, 4,949 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
