Kato HD1250VII
Series: Kato Hydraulic Excavator
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Kato HD excavators: how the number signals weight class and MR/LC the undercarriage
Kato has built hydraulic excavators since 1967, marking them with the "HD" code plus a model number. Across several model pairs in the SpecCodex database, the trailing digits of the number visibly track the approximate weight class in tonnes — the 40 recorded HD models span 10,500 to 46,200 kg operating weight, from compact to large building-site excavators.
Read on 3 more paragraphs
Trailing letters denote the body configuration: "MR" (Minimal/Mid Radius) marks machines with an especially short rear overhang for tight job sites, while "LC" (Long Crawler) denotes widened, elongated tracks giving more ground contact on soft terrain. Further suffixes such as "E" or "V" mark additional equipment or control variants within the same weight class.
For the machines recorded in the database, engine output ranges from 61 to 235 kW, displacement from 3,298 to 11,946 cm³, torque from 294 to 1,245 Nm, and cylinder count from 4 to 6.
When buying an MR variant, check the condition of the short rear body and counterweight mounting; on LC models, check track tension and track-pad wear. In general, check the hour meter, hydraulic cylinder seal condition, and test the bucket and boom under load. Models such as HD512, HD820, HD513MR and HD820LC illustrate the range of body configurations.
Sources: Kennwerte der Modelle Kato Hydraulic Excavator, – History, Kato Works Co., Ltd., – HD823MR-8, Kato CME (MR-Bauform), – Kato HD512E, RitchieSpecs, – Kato HD820V, RitchieSpecs
Technical data
Engine
| Engine model | 6D22Tcorrect |
|---|---|
| Power | 220.3 hp (162 kW)correct |
| Rated speed | 1,700 rpmcorrect |
| Torque | 1,010.1correct |
| Speed at max. torque | 1,200 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 11,149.8 cm³correct |
| Aspiration | turbochargedcorrect |
| Coolant capacity | 52.2 lcorrect |
| Engine oil capacity | 29.1 lcorrect |
Dimensions and weights
| Ground clearance | 481.6correct |
|---|---|
| Unladen weight | 29,500 kgcorrect |
Working data
| Pump flow | 582.2 l/mincorrect |
|---|---|
| Hydraulic oil capacity | 480.4 lcorrect |
| Hydraulic pressure | 328.2 barcorrect |
| Fuel tank capacity | 510.3 lcorrect |
Other data
| Cab height | 3,011.4correct |
|---|---|
| System voltage | 24 Vcorrect |
More machines with this engine (6D22T, 4)
Where this model stands
Power-to-weight ratio: 5.5 kW/t (162 kW / 29.5 t)
Stronger than 73% of the excavators & compaction in the register — out of 1,666 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Kato HD1250VII have?
The Kato HD1250VII delivers 220 hp.
How much does the Kato HD1250VII weigh?
The unladen weight is 29,500 kg.
What engine does the Kato HD1250VII have?
6 cylinders, 11,150 cm³ displacement.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
