Kato HD512

Series: Kato Hydraulic Excavator

Source: https://www.lectura-specs.com/en/model/agricultural-machiner

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The HD512 from Kato is part of the Kato Hydraulic Excavator series. The engine delivers 64.9 kW, has 4 cylinders, with a displacement of 3,298.7 cm³. Torque is 294.1 Nm. Rated speed is 2,200 rpm. The unladen weight is 11,884.1 kg. Ground clearance is 442 mm. The tank holds 250.2 litres. Maximum torque is reached at 1,700 rpm. The pump delivers 140.1 l/min. The hydraulic tank holds 155.2 litres. Working pressure is 294.4 bar. The cooling system holds 17 litres. The oil fill is 16.7 litres. The electrical system runs on 24 V. The engine fitted is the 4D31-T. The Kato Hydraulic Excavator series covers 40 models. Rated output within it ranges from 61.1 to 235 kW; the HD512 sits at the bottom of that range with 64.9 kW. Its immediate neighbours are the HD400VII below it with 61.1 kW and the HD450VII above it with 65 kW. 62 Kato models across 5 series are on record. The model is listed under Excavators & compaction. 18 verified figures from 1 source are on file.

Technical data

Engine

Engine model4D31-Tcorrect
Power64.9 kWcorrect
Rated speed2,200 rpmcorrect
Torque294.1correct
Speed at max. torque1,700 rpmcorrect
Cylinders4correct
Displacement3,298.7 cm³correct
Aspirationturbochargedcorrect
Coolant capacity17 lcorrect
Engine oil capacity16.7 lcorrect

Dimensions and weights

Ground clearance442correct
Unladen weight11,884.1 kgcorrect

Drivetrain and chassis

System voltage24 Vcorrect

Working data

Pump flow140.1 l/mincorrect
Hydraulic oil capacity155.2 lcorrect
Hydraulic pressure294.4 barcorrect
Fuel tank capacity250.2 lcorrect

Other data

Height2,712.7correct

Where this model stands

Power-to-weight ratio: 5.5 kW/t (65 kW / 11.9 t)

Stronger than 21% of the excavators & compaction in the register — out of 1,666 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Kato HD512 have?

The Kato HD512 delivers 64.9 kW.

How much does the Kato HD512 weigh?

The unladen weight is 11,884 kg.

What engine does the Kato HD512 have?

4 cylinders, 3,299 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
