JLG 2030ES – specifications
Series: JLG Scissor Lift
Build year not documented · Data origin: Directory data · sources
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The JLG 2030ES is a battery-powered scissor lift from the manufacturer JLG's ES series. This series comprises electric platforms designed for use indoors and on paved surfaces. The model belongs to the smaller variants of the series and is designed for compact working environments. The model designation follows the American convention, where the digits indicate the platform height in feet and the width in inches. As part of the Oshkosh Corporation, JLG produces these aerial work platforms as volume products for the global market.
Technically, the machine is characterized by a maximum working height of 8,100 mm and a lifting capacity of 360 kg. The platform offers an area of 2,300.2 mm in length and 760.2 mm in width, supplemented by a 900.2 mm extension for additional reach. The drive is provided by four batteries with a capacity of 200 Ah at a system voltage of 24 V. The maximum speed is 4.8 km/h, which is designed for safe transport within halls. With a turning radius of 2,060 mm and non-marking solid tires in size 16x5, the unit is suitable for sensitive floors. The raising and lowering times are 30 seconds each, while the ground clearance of 88.1 mm accounts for obstacles on the floor.
In comparison within the series, the JLG 2030ES ranks 21st out of 24 models in terms of empty weight. The weight of 1,700 kg positions the machine in the lower range of the series, which covers a span from 122.9 to 7,711.1 kg. The next smaller model is the 2032ES at 1,637.5 kg, while the 2632ES at 2,102.4 kg follows as the next larger model. This classification shows that the 2030ES belongs to the lighter scissor lifts, which supports transport and maneuverability in confined spaces.
JLG scissor lifts ES, R, RT, LE and CRT/LRT – from McConnellsburg, Pennsylvania: the number as platform height in feet and width in inches, electric for the hall, diesel for the site, 18 to 61 kW
JLG of McConnellsburg, Pennsylvania, is the world's largest maker of aerial work platforms – founded in 1969 by John L. Grove, who gave it its name, part of the Oshkosh group since 2006 – and scissor lifts are the volume product. The type logic follows the American convention: the first digits give the platform height in feet, the last the platform width in inches – a 1930ES is 19 ft high and 30 in wide, a 3246ES 32 ft and 46 in, a 4394RT 43 ft and 94 in. The letters name drive and duty: ES stands for Electric Slab, the battery-powered indoor lift with electric drive motors, R for the entry range, RT for Rough Terrain with diesel engine and all-wheel drive, LE for the electric rough-terrain lift, CRT and LRT for Compact and Large Rough Terrain, M for the version with mobile drive; the RTS models are older rough-terrain lifts.
Read on 3 more paragraphs
The register lists 24 versions with service weights from 123 to 7,711 kg, lengths from 1,753 to 5,180 mm, widths from 760 to 2,408 mm and platform capacities from 230 to 1,020 kg; the diesel models deliver 18.3 to 61.1 kW with Kubota engines, the older ones with Ford VSG-413 and LRG-425 petrol engines.
The 760 mm wide 1930ES is the most-hired work platform in the world – it drives through any standard door and lifts two people to 5.8 m platform height; the 4394RT with 94 inch width and extension deck is the site lift for façades and hall roofs.
On used lifts, operating hours, battery condition on ES models, play in scissor pins and rails, hydraulic tightness, the function of tilt and overload sensors and a valid periodic inspection are what count.
Sources: SpecCodex register, model data: JLG Scherenbühnen, JLG Industries (Oshkosh, Hersteller)
Technical data
Engine
| Drive type | electriccorrect |
|---|
Dimensions and weights
| Length | 2,300 mmcorrect |
|---|---|
| Width | 760 mmcorrect |
| Ground clearance | 88.1 mmcorrect |
| Unladen weight | 1,700 kgcorrect |
| Platform length | 2,300.2 mmcorrect |
| Platform width | 760.2 mmcorrect |
Drivetrain and chassis
| Tyre size | 16x5correct |
|---|---|
| Tyre type | Solid, Non-markingcorrect |
| Top speed | 4.8 km/hcorrect |
| Turning radius | 2,060 mmcorrect |
Working data
| Lifting capacity | 360 kgcorrect |
|---|---|
| Working height | 8,100 mmcorrect |
| Hydraulic oil capacity | 4.9 lcorrect |
| Lift time | 30 scorrect |
| Lowering time | 30 scorrect |
| Platform extension | 900.2 mmcorrect |
| Platform capacity | 363 kgcorrect |
Electrical data
| Battery capacity | 200 Ahcorrect |
|---|---|
| Number of batteries | 4correct |
Other data
| System voltage | 24 Vcorrect |
|---|
