Fordson E 27 N-D
Built: 1948–1952 · Series: Major
More machines from model year 1948
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Fordson Major – British Post-War Tractor From 1945 to the 1960s: four- to six-cylinder engines with 19.9 to 38.6 kW (27 to 52.5 hp), 3,610 to 4,728 cm³ displacement
The Fordson Major began in 1945 with the E27N model and was developed through several generations: the New Major (E1A) from 1951, then the Power Major from 1958. Over this span, engine output in the register grew from 19.9 to 38.6 kW, with models rated in horsepower spanning 27 to 52.5 hp, using four- to six-cylinder engines with displacement from 3,610 to 4,728 cm³.
Read on 3 more paragraphs
Recorded operating weight runs from 1,842 to 4,189 kg, wheelbase from 1,956 to 2,032 mm. Top speed of the listed models spans 8 to 22 km/h, typical of tractors from this era without gearing designed for road use.
The Fordson Major was one of the most widely used post-war tractors in Britain and many export markets, and it served as the base for numerous conversions, such as County or Roadless four-wheel-drive kits. For historic examples, the exact variant matters most: engine, gearbox and hydraulic system differ considerably between the early E27N and the later Major model years.
During this period, the Fordson Major was also characteristically available on the British market with carburettor engines running on petrol or the cheaper tractor vaporising oil (TVO, listed in the register as Petroleum), alongside the diesel version; the TVO system needed a preheated carburettor and a small petrol tank for cold starting, as the oil would not vaporise reliably in a cold engine.
Sources: SpecCodex register, model data: Fordson Major
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 45 hp (33.1 kW)correct |
| Rated speed | 1,500 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 4,728 cm³correct |
| Bore | 88.9 mmcorrect |
| Stroke | 127 mmcorrect |
| Injection pressure | 120 barcorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 3,378 mmcorrect |
|---|---|
| Width | 1,651 mmcorrect |
| Height | 2,083 mmcorrect |
| Wheelbase | 1,956 mmcorrect |
| Ground clearance | 305 mmcorrect |
| Unladen weight | 2,367 kgcorrect |
Drivetrain and chassis
| Drive | rear-wheel drivecorrect |
|---|---|
| Gearbox | 3 V/1 Rcorrect |
| Front tyres | 6.00-19correct |
| Rear tyres | 11.00-36correct |
| Top speed | 15.5 km/hcorrect |
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|---|
| Units built | 23,259correct |
Where this model stands
Power-to-weight ratio: 14 kW/t (33 kW / 2.4 t)
Power class: Universal (40–100 hp)
Stronger than 29% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Fordson E 27 N-D have?
The Fordson E 27 N-D delivers 45 hp.
How much does the Fordson E 27 N-D weigh?
The unladen weight is 2,367 kg.
What engine does the Fordson E 27 N-D have?
6 cylinders, 4,728 cm³ displacement, Diesel.
How fast does the Fordson E 27 N-D go?
Top speed is 15.5 km/h.
What are the dimensions of the Fordson E 27 N-D?
3,378 mm × 1,651 mm × 2,083 mm.
When was the Fordson E 27 N-D built?
Production years: 1948–1952.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 23 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
