Fendt Favorit 4 – specifications
Built: 1966–1967 · Series: Favorit
With the Favorit 4, Fendt offers a model from the Favorit series. Production: 1966–1967. The engine delivers 80 hp (59 kW), has 6 cylinders, with a displacement of 4,464 cm³. Rated speed is 2,300 rpm. The machine is 3,870 mm long, 1,950 mm wide and 1,620 mm high. The unladen weight is 3,200 kg. The wheelbase measures 2,570 mm. Top speed is 30 km/h. The engine is water-cooled. Tyres: front 10-20 AS, rear 15-30 AS. The fuel is diesel. Construction: unit construction (no separate frame). The PTO runs at 540/1000 rpm. Around 19 units were built. The Favorit series covers 44 models. Rated output within it ranges from 40 to 110 hp; the Favorit 4 sits in the middle of that range with 80 hp. Its immediate neighbours are the Favorit 3s below it with 62 hp and the Favorit 4 S/SA above it with 90 hp. Unladen weight within it ranges from 2,330 to 4,590 kg; here the Favorit 4 sits in the lower part of that range with 3,200 kg. 1545 Fendt models across 89 series are on record.
Data for the version built 1966–1967 · Data origin: Reference work (Wikipedia/Wikibooks) · sources
More machines from model year 1966
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Fendt Favorit – Tractor Series Since 1958: Forerunner of Stepless Vario Technology, three- to six-cylinder diesels with 29.3 to 110 kW (40 to 150 hp), 2,976 to 6,240 cm³ displacement
Fendt introduced the Favorit name in 1958 with the Favorit 1 and developed the series over several decades. The recorded models span a wide power band: output from 29.3 to 110 kW, with models rated in horsepower from 40 to 150 hp, using three- to six-cylinder engines with displacement from 2,976 to 6,240 cm³.
Read on 3 more paragraphs
Recorded operating weight runs from 2,330 to 6,800 kg, wheelbase from 2,168 to 2,696 mm, and top speed of the listed models spans 20 to 30 km/h. In 1995 Fendt presented, in a Favorit model, the first production-ready stepless Vario transmission in tractor manufacturing – a technical milestone that still shapes the brand's model policy today.
Across many model years, the Favorit series occupied the upper-mid to premium segment of the Fendt line-up. When buying a used Favorit, distinguishing early mechanical model years from later Vario versions matters, since the operating concept and service demands differ fundamentally.
With a power range up to 110 kW, the Favorit series' three-point hitch spanned from category I on the smaller models to category II under ISO 730 at the upper end; the most powerful Favorit Vario versions already approached the class otherwise reserved for category III. Early Favorit model years before 1999 still ran without any EU emissions certification, while later Vario models already fell under the first European emissions stages.
Sources: SpecCodex register, model data: Fendt Favorit, Fendt
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 80 hp (59 kW)correct |
| Rated speed | 2,300 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 4,464 cm³correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 3,870 mmcorrect |
|---|---|
| Width | 1,950 mmcorrect |
| Height | 1,620 mmcorrect |
| Wheelbase | 2,570 mmcorrect |
| Ground clearance | ca. 460 mmcorrect |
| Unladen weight | 3,200 kgcorrect |
Drivetrain and chassis
| Drive | four-wheel drivecorrect |
|---|---|
| Gearbox | 16/8-Synchrongetriebecorrect |
| Front tyres | 10-20 AScorrect |
| Rear tyres | 15-30 AScorrect |
| Top speed | 30 km/hcorrect |
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|---|
| Units built | 19correct |
Other data
| PTO speed | 540/1000 rpmcorrect |
|---|
Frequently asked questions
Where this model stands
Power-to-weight ratio: 18.4 kW/t (59 kW / 3.2 t)
Power class: Universal (40–100 hp)
Stronger than 55% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
