Case 495 (DT) – specifications
Built: 1990–1993 · Series: 95 er-Baureihe
The 95er series from Case includes the 495 (DT). Production: 1990–1993. The engine delivers 52 hp (38.2 kW), has 3 cylinders, with a displacement of 2,933 cm³. Torque is 182 Nm. Rated speed is 2,180 rpm. The machine is 3,454 mm long, 1,676 mm wide and 2,375 mm high. The unladen weight is 2,358 kg. The wheelbase measures 2,010 mm. Ground clearance is 561 mm. Top speed is 30 km/h. Transmission: 8 V/4 R, 16 V/8 R and 8 V/8 R. The engine is water-cooled. Tyres: front 6.00-16 ASF (DT: 8.3 R 24 AS), rear 14.9 R 28 (DT: 12.4 R 32 AS). The fuel is diesel. The bore measures 98.4 mm. The stroke is 128.5 mm. The compression ratio is 15:1. Maximum torque is reached at 1,400 rpm. Construction: unit construction (no separate frame). Injection pressure is 225 bar. The 95 er-Baureihe series covers 6 models. Rated output within it ranges from 52 to 90 hp; the 495 (DT) sits at the bottom of that range with 52 hp. Its immediate neighbours are the 595 (DT) above it with 60 hp. Unladen weight within it ranges from 2,358 to 3,113 kg; here the 495 (DT) sits at the bottom of that range with 2,358 kg. 636 Case models across 32 series are on record.
Data for the version built 1990–1993 · Data origin: Reference work (Wikipedia/Wikibooks) · sources
More machines from model year 1990
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Case International 95 series (1986–1993) – the David Brown heirs from Meltham: 495 to 995, the final digits 95 as series, the first digit as size class, DT for four-wheel drive
The 95 series comes from Meltham in Yorkshire, the David Brown plant Case had taken over in 1972: after the merger of Case and International Harvester in 1985 the David Brown tractors continued in red as Case International, and the 95s were the range with which the brand replaced the 94s – until Case IH closed the Meltham plant in 1988 and moved production to Doncaster. The type logic: the final digits 95 mark the series, the first digit orders the size in ascending order – 495 about 50 hp, 595 about 60, 695 about 70, 795 about 75, 895 about 85, 995 about 90 hp – DT four-wheel drive. The engines are David Brown's own three- and four-cylinder diesels of 2.9 to 4.4 litres at 2,180 to 2,400 rpm, the transmissions David Brown's synchromesh gearboxes with the Hydra-Shift powershift step in the larger models; the hydraulics carried David Brown's Selectamatic system.
Read on 3 more paragraphs
The register lists 6 versions with 38.2 to 66.2 kW from three- and four-cylinders of 2,933 to 4,389 cm³, torque from 182 to 299 Nm, unladen weights from 2,358 to 3,113 kg, lengths from 3,454 to 3,845 mm, widths from 1,676 to 1,981 mm and heights from 2,375 to 2,670 mm.
The 95s are still at work on small farms in Britain and Ireland today and are the last tractors with David Brown technology; the successors 3200 and 4200 from Doncaster came with IH engines from Neuss.
On used tractors, operating hours, engine condition and injection pump, clutch, gearbox and Hydra-Shift, Selectamatic hydraulics, four-wheel-drive clutch on DT models and sheet metal count; parts run through Case IH and David Brown specialists in Britain.
Sources: SpecCodex register, model data: Case International 95er-Baureihe, Case IH (manufacturer)
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 52 hp (38.2 kW)correct |
| Rated speed | 2,180 rpmcorrect |
| Torque | 182 Nmcorrect |
| Speed at max. torque | 1,400 rpmcorrect |
| Cylinders | 3correct |
| Displacement | 2,933 cm³correct |
| Bore | 98.4 mmcorrect |
| Stroke | 128.5 mmcorrect |
| Compression ratio | 15correct |
| Injection pressure | 225 barcorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 3,454 mmcorrect |
|---|---|
| Width | 1,676 mmcorrect |
| Height | 2,375 mmcorrect |
| Wheelbase | 2,010 mmcorrect |
| Ground clearance | 561 mmcorrect |
| Unladen weight | 2,358 kgcorrect |
Drivetrain and chassis
| Drive | rear- or four-wheel drivecorrect |
|---|---|
| Gearbox | 8 V/4 R, 16 V/8 R and 8 V/8 Rcorrect |
| Front tyres | 6.00-16 ASF (DT: 8.3 R 24 AS)correct |
| Rear tyres | 14.9 R 28 (DT: 12.4 R 32 AS)correct |
| Top speed | 30 km/hcorrect |
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|
Frequently asked questions
Where this model stands
Power-to-weight ratio: 16.2 kW/t (38 kW / 2.4 t)
Power class: Universal (40–100 hp)
Stronger than 36% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
