Case IH 9280
Built: 1990–1995 · Series: 9200 er-Baureihe
More machines from model year 1990
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Case IH 9200 series (1990–1995) – the second Steiger generation under Case IH from Fargo: 9230 to 9280, the last digits as power step, wheeled and Quadtrac versions, Cummins and Case six-cylinders of 8.3 and 10 litres
The 9200 series was the second articulated-tractor generation Case IH built at the Fargo plant in North Dakota after the takeover of Steiger in 1986 – the successor to the 9100s of 1987 and the range in which the first four-track tractor went into series production in 1996 with the 9370 Quadtrac. The type logic: 92 marks the range, the last two digits the power step – 9230 about 235 hp, 9250 about 275, 9270 about 335, 9280 about 375 hp – the versions comprise wheeled articulated tractors on duals or triples and, in the late range, the Quadtrac. The engines are the Case six-cylinder 6TA-830 of 8.3 litres in the small and the Cummins N14 and Case-Cummins 6TA-1000 of 10 litres in the big models, at 2,100 to 2,200 rpm; the transmission is the 12- or 24-speed powershift, optionally the synchromesh gearbox.
Read on 3 more paragraphs
The register lists 6 versions with 172.8 to 279.5 kW from six-cylinders of 8,268 to 10,016 cm³, torque up to 1,324 Nm, unladen weights from 10,935 to 15,728 kg, lengths from 6,410 to 7,610 mm, widths from 2,661 to 4,005 mm and heights from 3,198 to 3,870 mm.
The 9200s are the tractors with which Case IH held the prairie articulated-tractor market against John Deere and Versatile; in 1996 the 9300 series followed with the Quadtrac in series production, in 2000 the STX.
On used tractors, operating hours, engine (Cummins and Case parts available), powershift (clutch packs, electronics), articulation joint and steering cylinders, axles and tyres, hydraulics count; parts run through CNH and Cummins.
Sources: SpecCodex register, model data: Case IH 9200er-Baureihe, Case IH (CNH, Hersteller, Werk Fargo)
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 380 hp (279.5 kW)correct |
| Rated speed | 2,100 rpmcorrect |
| Torque | 1,715 Nmcorrect |
| Speed at max. torque | 1,400 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 10,016 cm³correct |
| Bore | 139.7 mmcorrect |
| Stroke | 152.4 mmcorrect |
| Compression ratio | 14.5correct |
| Injection pressure | 103 barcorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 7,610 mmcorrect |
|---|---|
| Width | 3,890 mmcorrect |
| Height | 3,870 mmcorrect |
| Wheelbase | 1,943 mmcorrect |
| Ground clearance | 424 mmcorrect |
| Unladen weight | 15,728 kgcorrect |
Drivetrain and chassis
| Drive | four-wheel drivecorrect |
|---|---|
| Gearbox | 12 V/3 Rcorrect |
| Forward gears | 12correct |
| Reverse gears | 3correct |
| Front tyres | 24.5 R 32 AScorrect |
| Rear tyres | 24.5 R 32 AScorrect |
| Top speed | 30 km/hcorrect |
Working data
| Fuel tank capacity | 948 lcorrect |
|---|
Origin and approval
| Construction | articulated framecorrect |
|---|
Where this model stands
Power-to-weight ratio: 17.8 kW/t (280 kW / 15.7 t)
Power class: Heavy (> 180 hp)
Stronger than 98% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Case IH 9280 have?
The Case IH 9280 delivers 380 hp.
How much does the Case IH 9280 weigh?
The unladen weight is 15,728 kg.
What engine does the Case IH 9280 have?
6 cylinders, 10,016 cm³ displacement, Diesel.
How fast does the Case IH 9280 go?
Top speed is 30 km/h.
What are the dimensions of the Case IH 9280?
7,610 mm × 3,890 mm × 3,870 mm.
When was the Case IH 9280 built?
Production years: 1990–1995.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
