AGCO Allis 5680

Built: 1991–1997 · Series: 5.600 er - Baureihe

More machines from model year 1991

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The AGCO Allis 5680 belongs to the 5600er series. Production: 1991–1997. The engine delivers 80 hp (58.8 kW), has 4 cylinders, with a displacement of 4,000 cm³. The engine comes from SAME. Torque is 261 Nm. Rated speed is 2,500 rpm. The machine is 3,919 mm long, 1,941 mm wide and 2,530 mm high. The unladen weight is 3,025 kg. The wheelbase measures 2,360 mm. Ground clearance is 500 mm. Top speed is 30 km/h. Transmission: 12 V/12 R, 16 V/16 R and 24 V/12 R. The engine is air-cooled. Tyres: front 7.50-16 ASF (4 WD: 12.4 R 24 AS), rear 16.9 R 30 AS. The model was built in Italy. The fuel is diesel. The bore measures 105 mm. The stroke is 115.5 mm. The compression ratio is 17.1:1. Maximum torque is reached at 1,305 rpm. Construction: unit construction (no separate frame). The 5.600 er - Baureihe series covers 4 models. Rated output within it ranges from 48 to 80 hp; the 5680 sits at the top of that range with 80 hp. Its immediate neighbours are the 5670 below it with 70 hp. Unladen weight within it ranges from 2,055 to 3,025 kg; here the 5680 sits at the top of that range with 3,025 kg. 58 AGCO Allis models across 14 series are on record.

AGCO Allis 5600 series – compact tractors from the US brand based in Duluth: 5650 to 5680 with SAME engines, 35 to 59 kW, three- and four-cylinder engines of 3,000 to 4,000 cm³

AGCO Allis was, in the 1990s, one of the US tractor brands of the AGCO group headquartered in Duluth, Georgia; the brand name traces back to Allis-Chalmers, whose farm-machinery division passed, via the intermediate company Deutz-Allis, to the newly formed Allis-Gleaner Corporation – AGCO for short – in 1990. The models covered here, 5650 to 5680, form the brand's 5600 compact class; according to the register, their engines come from the Italian maker SAME, today part of the SAME Deutz-Fahr group.

Read on 3 more paragraphs

The register lists here 4 versions with 35.3 to 58.8 kW, or 46 to 73 hp, from three- and four-cylinder engines of 3,000 to 4,000 cm³, unladen weights from 2,055 to 3,025 kg, torque from 167 to 261 Nm, lengths from 3,378 to 3,919 mm, widths from 1,694 to 1,941 mm and heights from 2,233 to 2,530 mm.

The 5600 series was positioned in the compact segment alongside brands such as Massey Ferguson, Ford and the emerging Japanese compact tractors, aimed at smaller farms, orchards, vineyards and municipal use; the AGCO Allis brand was gradually withdrawn from the market in the late 1990s in favour of other AGCO brands.

On a used buy, for the SAME engines what counts is the condition of the injection pump and cooling system, the tightness of the hydraulics, corrosion on the wings and chassis, and the limited parts supply, since the brand has long been discontinued and spares must be sourced partly through SAME Deutz-Fahr and partly through independent farm-machinery dealers.

Sources: SpecCodex register, model data: AGCO Allis 5600er-Baureihe

Technical data

Engine

Engine make	SAMEcorrect
Fuel	dieselcorrect
Power	80 hp (58.8 kW)correct
Rated speed	2,500 rpmcorrect
Torque	261 Nmcorrect
Speed at max. torque	1,305 rpmcorrect
Cylinders	4correct
Displacement	4,000 cm³correct
Bore	105 mmcorrect
Stroke	115.5 mmcorrect
Compression ratio	17.1correct
Cooling	air-cooledcorrect

Dimensions and weights

Length	3,919 mmcorrect
Width	1,941 mmcorrect
Height	2,530 mmcorrect
Wheelbase	2,360 mmcorrect
Ground clearance	500 mmcorrect
Unladen weight	3,025 kgcorrect

Drivetrain and chassis

Drive	rear- and four-wheel drivecorrect
Gearbox	12 V/12 R, 16 V/16 R and 24 V/12 Rcorrect
Front tyres	7.50-16 ASF (4 WD: 12.4 R 24 AS)correct
Rear tyres	16.9 R 30 AScorrect
Top speed	30 km/hcorrect

Origin and approval

Plant	Italycorrect
Construction	unit construction (no separate frame)correct

Where this model stands

Power-to-weight ratio: 19.4 kW/t (59 kW / 3 t)

Power class: Universal (40–100 hp)

Stronger than 54% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the AGCO Allis 5680 have?

The AGCO Allis 5680 delivers 80 hp.

How much does the AGCO Allis 5680 weigh?

The unladen weight is 3,025 kg.

What engine does the AGCO Allis 5680 have?

4 cylinders, 4,000 cm³ displacement, Diesel.

How fast does the AGCO Allis 5680 go?

Top speed is 30 km/h.

What are the dimensions of the AGCO Allis 5680?

3,919 mm × 1,941 mm × 2,530 mm.

When was the AGCO Allis 5680 built?

Production years: 1991–1997.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
Shift the gearbox cold and warm — jumps only show up at temperature.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
