AGCO Allis 5660
Built: 1994–1999 · Series: 5.600 er - Baureihe
More machines from model year 1994
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
AGCO Allis 5600 series – compact tractors from the US brand based in Duluth: 5650 to 5680 with SAME engines, 35 to 59 kW, three- and four-cylinder engines of 3,000 to 4,000 cm³
AGCO Allis was, in the 1990s, one of the US tractor brands of the AGCO group headquartered in Duluth, Georgia; the brand name traces back to Allis-Chalmers, whose farm-machinery division passed, via the intermediate company Deutz-Allis, to the newly formed Allis-Gleaner Corporation – AGCO for short – in 1990. The models covered here, 5650 to 5680, form the brand's 5600 compact class; according to the register, their engines come from the Italian maker SAME, today part of the SAME Deutz-Fahr group.
Read on 3 more paragraphs
The register lists here 4 versions with 35.3 to 58.8 kW, or 46 to 73 hp, from three- and four-cylinder engines of 3,000 to 4,000 cm³, unladen weights from 2,055 to 3,025 kg, torque from 167 to 261 Nm, lengths from 3,378 to 3,919 mm, widths from 1,694 to 1,941 mm and heights from 2,233 to 2,530 mm.
The 5600 series was positioned in the compact segment alongside brands such as Massey Ferguson, Ford and the emerging Japanese compact tractors, aimed at smaller farms, orchards, vineyards and municipal use; the AGCO Allis brand was gradually withdrawn from the market in the late 1990s in favour of other AGCO brands.
On a used buy, for the SAME engines what counts is the condition of the injection pump and cooling system, the tightness of the hydraulics, corrosion on the wings and chassis, and the limited parts supply, since the brand has long been discontinued and spares must be sourced partly through SAME Deutz-Fahr and partly through independent farm-machinery dealers.
Sources: SpecCodex register, model data: AGCO Allis 5600er-Baureihe
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 58 hp (42.7 kW)correct |
| Rated speed | 2,350 rpmcorrect |
| Torque | 186 Nmcorrect |
| Speed at max. torque | 1,544 rpmcorrect |
| Cylinders | 3correct |
| Displacement | 3,000 cm³correct |
| Bore | 105 mmcorrect |
| Stroke | 115.5 mmcorrect |
| Compression ratio | 17correct |
| Cooling | air-cooledcorrect |
Dimensions and weights
| Length | 3,589 mmcorrect |
|---|---|
| Width | 1,844 mmcorrect |
| Height | 2,248 mmcorrect |
| Wheelbase | 2,106 mmcorrect |
| Ground clearance | 500 mmcorrect |
| Unladen weight | 2,265 kgcorrect |
Drivetrain and chassis
| Drive | rear- and four-wheel drivecorrect |
|---|---|
| Gearbox | 12 V/12 R or 16 V/8 Rcorrect |
| Forward gears | 12correct |
| Reverse gears | 12correct |
| Front tyres | 7.50-16 ASF (4 WD: 11.2 R 24 AS)correct |
| Rear tyres | 16.9 R 30 AScorrect |
| Top speed | 30 km/hcorrect |
Working data
| Fuel tank capacity | 57 lcorrect |
|---|
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|
Other data
| Linkage category | Cat IIcorrect |
|---|---|
| PTO speed | 540/1000 rpmcorrect |
Where this model stands
Power-to-weight ratio: 18.9 kW/t (43 kW / 2.3 t)
Power class: Universal (40–100 hp)
Stronger than 40% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the AGCO Allis 5660 have?
The AGCO Allis 5660 delivers 58 hp.
How much does the AGCO Allis 5660 weigh?
The unladen weight is 2,265 kg.
What engine does the AGCO Allis 5660 have?
3 cylinders, 3,000 cm³ displacement, Diesel.
How fast does the AGCO Allis 5660 go?
Top speed is 30 km/h.
What are the dimensions of the AGCO Allis 5660?
3,589 mm × 1,844 mm × 2,248 mm.
When was the AGCO Allis 5660 built?
Production years: 1994–1999.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
