AGCO Allis 5670

Built: 1991–1999 · Series: 5.600 er - Baureihe

More machines from model year 1991

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The 5600er series from AGCO Allis includes the 5670. Production: 1991–1999. The engine delivers 70 hp (51.5 kW), has 4 cylinders, with a displacement of 4,000 cm³. The engine comes from SAME. Torque is 239 Nm. Rated speed is 2,350 rpm. The machine is 3,851 mm long, 1,859 mm wide and 2,451 mm high. The unladen weight is 2,810 kg. The wheelbase measures 2,319 mm. Ground clearance is 450 mm. Top speed is 30 km/h. Transmission: 12 V/12 R, 16 V/16 R and 24 V/12 R. The engine is air-cooled. Tyres: front 7.50-16 ASF (4 WD: 12.4 R 24 AS), rear 16.9 R 30 AS. The model was built in Italy. The fuel is diesel. The bore measures 105 mm. The stroke is 115.5 mm. The compression ratio is 17.1:1. Maximum torque is reached at 1,266 rpm. Construction: unit construction (no separate frame). The 5.600 er - Baureihe series covers 4 models. Rated output within it ranges from 48 to 80 hp; the 5670 sits in the upper part of that range with 70 hp. Its immediate neighbours are the 5660 below it with 58 hp and the 5680 above it with 80 hp. Unladen weight within it ranges from 2,055 to 3,025 kg; here the 5670 sits in the upper part of that range with 2,810 kg. 58 AGCO Allis models across 14 series are on record.

AGCO Allis 5600 series – compact tractors from the US brand based in Duluth: 5650 to 5680 with SAME engines, 35 to 59 kW, three- and four-cylinder engines of 3,000 to 4,000 cm³

AGCO Allis was, in the 1990s, one of the US tractor brands of the AGCO group headquartered in Duluth, Georgia; the brand name traces back to Allis-Chalmers, whose farm-machinery division passed, via the intermediate company Deutz-Allis, to the newly formed Allis-Gleaner Corporation – AGCO for short – in 1990. The models covered here, 5650 to 5680, form the brand's 5600 compact class; according to the register, their engines come from the Italian maker SAME, today part of the SAME Deutz-Fahr group.

Read on 3 more paragraphs

The register lists here 4 versions with 35.3 to 58.8 kW, or 46 to 73 hp, from three- and four-cylinder engines of 3,000 to 4,000 cm³, unladen weights from 2,055 to 3,025 kg, torque from 167 to 261 Nm, lengths from 3,378 to 3,919 mm, widths from 1,694 to 1,941 mm and heights from 2,233 to 2,530 mm.

The 5600 series was positioned in the compact segment alongside brands such as Massey Ferguson, Ford and the emerging Japanese compact tractors, aimed at smaller farms, orchards, vineyards and municipal use; the AGCO Allis brand was gradually withdrawn from the market in the late 1990s in favour of other AGCO brands.

On a used buy, for the SAME engines what counts is the condition of the injection pump and cooling system, the tightness of the hydraulics, corrosion on the wings and chassis, and the limited parts supply, since the brand has long been discontinued and spares must be sourced partly through SAME Deutz-Fahr and partly through independent farm-machinery dealers.

Sources: SpecCodex register, model data: AGCO Allis 5600er-Baureihe

Technical data

Engine

Engine make	SAMEcorrect
Fuel	dieselcorrect
Power	70 hp (51.5 kW)correct
Rated speed	2,350 rpmcorrect
Torque	239 Nmcorrect
Speed at max. torque	1,266 rpmcorrect
Cylinders	4correct
Displacement	4,000 cm³correct
Bore	105 mmcorrect
Stroke	115.5 mmcorrect
Compression ratio	17.1correct
Cooling	air-cooledcorrect

Dimensions and weights

Length	3,851 mmcorrect
Width	1,859 mmcorrect
Height	2,451 mmcorrect
Wheelbase	2,319 mmcorrect
Ground clearance	450 mmcorrect
Unladen weight	2,810 kgcorrect

Drivetrain and chassis

Drive	rear- and four-wheel drivecorrect
Gearbox	12 V/12 R, 16 V/16 R and 24 V/12 Rcorrect
Front tyres	7.50-16 ASF (4 WD: 12.4 R 24 AS)correct
Rear tyres	16.9 R 30 AScorrect
Top speed	30 km/hcorrect

Origin and approval

Plant	Italycorrect
Construction	unit construction (no separate frame)correct

Where this model stands

Power-to-weight ratio: 18.3 kW/t (52 kW / 2.8 t)

Power class: Universal (40–100 hp)

Stronger than 48% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the AGCO Allis 5670 have?

The AGCO Allis 5670 delivers 70 hp.

How much does the AGCO Allis 5670 weigh?

The unladen weight is 2,810 kg.

What engine does the AGCO Allis 5670 have?

4 cylinders, 4,000 cm³ displacement, Diesel.

How fast does the AGCO Allis 5670 go?

Top speed is 30 km/h.

What are the dimensions of the AGCO Allis 5670?

3,851 mm × 1,859 mm × 2,451 mm.

When was the AGCO Allis 5670 built?

Production years: 1991–1999.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
Shift the gearbox cold and warm — jumps only show up at temperature.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
