Start › Excavators & compaction › Volvo › EC340D

Volvo EC340D

Series: Volvo Hydraulic Excavator

Source: https://www.truck1.eu/municipal-special-vehicles/euro-4/dies

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Volvo EC340D is a model in the Volvo Hydraulic Excavator series. The engine delivers 297.1 hp (211 kW), has 6 cylinders, with a displacement of 12,798.3 cm³. Torque is 1,580.1 Nm. Rated speed is 1,700 rpm. The unladen weight is 34,137.4 kg. Ground clearance is 536.4 mm. The tank holds 620.1 litres. Maximum torque is reached at 1,300 rpm. The pump delivers 600.4 l/min. The hydraulic tank holds 500.1 litres. Working pressure is 353 bar. The cooling system holds 60.2 litres. The oil fill is 42 litres. The electrical system runs on 24 V. The engine fitted is the D13H. The Volvo Hydraulic Excavator series covers 53 models. Rated output within it ranges from 99.4 to 534.3 hp; the EC340D sits in the middle of that range with 297.1 hp. Its immediate neighbours are the EC380DL below it with 296.1 hp and the EC350E above it with 312.8 hp. 5366 Volvo models across 29 series are on record. The model is listed under Excavators & compaction. 19 verified figures from 1 source are on file.

Technical data

Engine

Engine modelD13Hcorrect
Power297.1 hp (211 kW)correct
Rated speed1,700 rpmcorrect
Torque1,580.1correct
Speed at max. torque1,300 rpmcorrect
Cylinders6correct
Displacement12,798.3 cm³correct
AspirationTurbocharged and Intercooledcorrect
Coolant capacity60.2 lcorrect
Engine oil capacity42 lcorrect

Dimensions and weights

Ground clearance536.4correct
Unladen weight34,137.4 kgcorrect

Drivetrain and chassis

System voltage24 Vcorrect

Working data

Pump flow600.4 l/mincorrect
Hydraulic oil capacity500.1 lcorrect
Hydraulic pressure353 barcorrect
Fuel tank capacity620.1 lcorrect

Other data

Height3,227.8correct

Where this model stands

Power-to-weight ratio: 6.2 kW/t (211 kW / 34.1 t)

Stronger than 83% of the excavators & compaction in the register — out of 1,666 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Volvo EC340D have?

The Volvo EC340D delivers 297 hp.

How much does the Volvo EC340D weigh?

The unladen weight is 34,137 kg.

What engine does the Volvo EC340D have?

6 cylinders, 12,798 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 19 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
