Volvo EC13XTV

Series: Volvo Mini Excavator

Source: https://www.technikboerse.com/gebraucht/bagger-789/volvo-124

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The EC13XTV from Volvo is part of the Volvo Mini Excavator series. The engine delivers 19.3 hp (11.2 kW), with a displacement of 952.1 cm³. Torque is 50 Nm. Rated speed is 2,800 rpm. The unladen weight is 1,361 kg. The tank holds 18.2 litres. Maximum torque is reached at 1,800 rpm. The pump delivers 31 l/min. The hydraulic tank holds 17.8 litres. Working pressure is 170 bar. The cooling system holds 5.3 litres. The oil fill is 3.8 litres. The engine fitted is the L3E2. The Volvo Mini Excavator series covers 28 models. Rated output within it ranges from 15.2 to 63.9 hp; the EC13XTV sits at the bottom of that range with 19.3 hp. Its immediate neighbours are the EC20 Variable Width Undercarriage below it with 19.1 hp and the ECR28 above it with 19.6 hp. 5366 Volvo models across 29 series are on record. The model is listed under Excavators & compaction. 16 verified figures from 1 source are on file.

Technical data

Engine

Engine modelL3E2correct
Power19.3 hp (11.2 kW)correct
Rated speed2,800 rpmcorrect
Torque50correct
Speed at max. torque1,800 rpmcorrect
Displacement952.1 cm³correct
Aspirationnaturalcorrect
Coolant capacity5.3 lcorrect
Engine oil capacity3.8 lcorrect

Dimensions and weights

Unladen weight1,361 kgcorrect

Working data

Pump flow31 l/mincorrect
Hydraulic oil capacity17.8 lcorrect
Hydraulic pressure170 barcorrect
Fuel tank capacity18.2 lcorrect

Other data

Height2,292.1correct

Where this model stands

Power-to-weight ratio: 8.2 kW/t (11 kW / 1.4 t)

Stronger than 12% of the mini excavators in the register — out of 400 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Volvo EC13XTV have?

The Volvo EC13XTV delivers 19.3 hp.

How much does the Volvo EC13XTV weigh?

The unladen weight is 1,361 kg.

What engine does the Volvo EC13XTV have?

952 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
