Volvo EC14

Series: Volvo Mini Excavator

Source: https://www.volvoce.com/deutschland/de-de/products/excavator

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Volvo Mini Excavator series from Volvo includes the EC14. The engine delivers 19.1 hp (11.3 kW), has 3 cylinders, with a displacement of 952.1 cm³. Torque is 54.1 Nm. Rated speed is 2,200 rpm. The unladen weight is 1,530 kg. Ground clearance is 210.3 mm. The tank holds 21.2 litres. Maximum torque is reached at 1,850 rpm. The pump delivers 32.2 l/min. The hydraulic tank holds 36.3 litres. Working pressure is 160 bar. The cooling system holds 4.5 litres. The oil fill is 3.8 litres. The electrical system runs on 12 V. The engine fitted is the L3E. The Volvo Mini Excavator series covers 28 models. Rated output within it ranges from 15.2 to 63.9 hp; the EC14 sits at the bottom of that range with 19.1 hp. Its immediate neighbours are the ECR 25 D below it with 15.8 hp and the EC13XR above it with 19.3 hp. 5366 Volvo models across 29 series are on record. The model is listed under Excavators & compaction. 18 verified figures from 1 source are on file.

Technical data

Engine

Engine modelL3Ecorrect
Power19.1 hp (11.3 kW)correct
Rated speed2,200 rpmcorrect
Torque54.1correct
Speed at max. torque1,850 rpmcorrect
Cylinders3correct
Displacement952.1 cm³correct
Coolant capacity4.5 lcorrect
Engine oil capacity3.8 lcorrect

Dimensions and weights

Ground clearance210.3correct
Unladen weight1,530 kgcorrect

Drivetrain and chassis

System voltage12 Vcorrect

Working data

Pump flow32.2 l/mincorrect
Hydraulic oil capacity36.3 lcorrect
Hydraulic pressure160 barcorrect
Fuel tank capacity21.2 lcorrect

Other data

Height2,191.5correct

Where this model stands

Power-to-weight ratio: 7.4 kW/t (11 kW / 1.5 t)

Stronger than 15% of the mini excavators in the register — out of 400 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Volvo EC14 have?

The Volvo EC14 delivers 19.1 hp.

How much does the Volvo EC14 weigh?

The unladen weight is 1,530 kg.

What engine does the Volvo EC14 have?

3 cylinders, 952 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
