Start › Mini excavators › Volvo › EC15BXTV

Volvo EC15BXTV

Series: Volvo Mini Excavator

Source: https://www.volvoce.com/deutschland/de-de/products/excavator

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Volvo Mini Excavator series from Volvo includes the EC15BXTV. The engine delivers 11.3 kW, has 3 cylinders, with a displacement of 950.4 cm³. Torque is 54.2 Nm. Rated speed is 2,200 rpm. The unladen weight is 1,735.4 kg. The tank holds 21.2 litres. Maximum torque is reached at 1,850 rpm. The pump delivers 31.8 l/min. The hydraulic tank holds 23.1 litres. Working pressure is 170 bar. The cooling system holds 4.5 litres. The oil fill is 3.8 litres. The electrical system runs on 12 V. The engine fitted is the L3E. The Volvo Mini Excavator series covers 28 models. Rated output within it ranges from 11.2 to 45.2 kW; the EC15BXTV sits at the bottom of that range with 11.3 kW. Its immediate neighbours are the EC13XTV below it with 11.2 kW and the EC 27 D above it with 11.6 kW. 5366 Volvo models across 29 series are on record. The model is listed under Excavators & compaction. 17 verified figures from 1 source are on file.

Technical data

Engine

Engine modelL3Ecorrect
Power11.3 kWcorrect
Rated speed2,200 rpmcorrect
Torque54.2correct
Speed at max. torque1,850 rpmcorrect
Cylinders3correct
Displacement950.4 cm³correct
AspirationNaturalcorrect
Coolant capacity4.5 lcorrect
Engine oil capacity3.8 lcorrect

Dimensions and weights

Unladen weight1,735.4 kgcorrect

Drivetrain and chassis

System voltage12 Vcorrect

Working data

Pump flow31.8 l/mincorrect
Hydraulic oil capacity23.1 lcorrect
Hydraulic pressure170 barcorrect
Fuel tank capacity21.2 lcorrect

Other data

Height2,252.5correct

Where this model stands

Power-to-weight ratio: 6.5 kW/t (11 kW / 1.7 t)

Stronger than 15% of the mini excavators in the register — out of 400 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Volvo EC15BXTV have?

The Volvo EC15BXTV delivers 11.3 kW.

How much does the Volvo EC15BXTV weigh?

The unladen weight is 1,735 kg.

What engine does the Volvo EC15BXTV have?

3 cylinders, 950 cm³ displacement.
