Volvo Construction Equipment D8M – specifications
Built: 2021-2026 · Series: Other models
The Volvo Construction Equipment D8M is a machine built by Volvo Construction Equipment. Production: 2021-2026. The fuel is 7-15 ppm Ultra Low Sulfur Diesel. The rated output is 191 kW. The engine is turbocharged. The engine meets emissions stage Tier 4 (Final or Phase In). Fuel reaches the combustion chamber through direct injection. The charge air is air-cooled. Charging is by a variable-geometry turbocharger. It is a four-stroke diesel engine. The cylinders are arranged in line. Rated output across the Volvo Construction Equipment range ranges from 191 to 393 kW; the D8M sits at the bottom of that range with 191 kW. Its immediate neighbours are the D13J above it with 218 kW. 12 Volvo Construction Equipment models across 4 series are on record.
Data for the version built 2021-2026 · Data origin: Official register · sources
More machines from model year 2021
Volvo Construction Equipment – other nonroad diesel engines: D8 to D16 outside the named ranges, 191 to 393 kW from 7.7 to 16.1-litre displacement, Tier 4
Volvo Construction Equipment, headquartered in Eskilstuna and Gothenburg, is the Volvo Group's construction-machinery division, sharing the technical base of its D engines with the group's truck and industrial engines but calibrating them independently for wheel loaders, articulated haulers and excavators. This page gathers the engines the register could not assign to a named range, from the D8, D11, D13 and D16 families – the number in the name roughly matches the displacement in litres, as confirmed by the engine family codes with 7.7, 10.8, 12.8 and 16.1 litres.
Read on 3 more paragraphs
The register lists here 8 versions with 191 to 393 kW rated output at 1,800 to 2,240 rpm, all inline six-cylinder engines with 110 to 144 mm bore and 135 to 165 mm stroke. Seven of the eight engines use a variable-geometry turbocharger, one a simple wastegate unit. The emission stage splits into Tier 4 (Final or Phase-in) with 5 and Interim Tier 4 with 3 versions, the power category is uniformly 130 to 560 kW. Maximum torque runs from 1,246 to 2,570 Nm at 1,000 to 1,450 rpm, model years from 2012 to 2026; the range is certified for both the other states and California.
Engines of these ranges power Volvo CE's heavy construction-machinery programme – wheel loaders, articulated haulers and large excavators used in quarrying, open-pit mining and earthmoving. Unlike the road engines of Volvo's sister brands, D engines in construction machinery are tuned for high pulling power at low speeds and long service life under varying load.
On a used purchase, the condition of the variable-geometry turbocharger and its actuation, the tightness of the exhaust gas recirculation and charge-air cooler, oil consumption, and operating hours relative to the machine's history all matter. Parts and service run through the Volvo CE dealer network.
Sources: SpecCodex register, model data: Volvo Construction Equipment (weitere Nonroad-Dieselmotoren), Volvo Construction Equipment (manufacturer), EPA-Zertifizierungsdaten Motoren
Technical data
Engine
| Engine code | 8-18correct |
|---|---|
| Engine family | MVSXL07.7STVcorrect |
| Engine families | PVSXL07.7STV; TVSXL07.7STV; MVSXL07.7STV; SVSXL07.7STV; NVSXL07.7STV; RVSXL07.7STVcorrect |
| Fuel | 7-15 ppm Ultra Low Sulfur Dieselcorrect |
| Rated output | 191 kWcorrect |
| Power band | 130<=kW<=560correct |
| Rated speed | 2,240 rpmcorrect |
| Maximum torque | 1,246 N·mcorrect |
| Speed at max. torque | 1,450 rpmcorrect |
| Cylinders | 6correct |
| Cylinder layout | in linecorrect |
| Bore | 110 mmcorrect |
| Stroke | 135 mmcorrect |
| Operating cycle | four-stroke dieselcorrect |
| Injection | direct injectioncorrect |
| Aspiration | turbochargedcorrect |
| Turbocharger type | Variable Geometry Turbochargercorrect |
| Charge-air cooling | aircorrect |
| Emissions stage | Tier 4 (Final or Phase In)correct |
Origin and approval
| Version | 8-18correct |
|---|---|
| Built from | 2021correct |
| Built to | 2026correct |
| Model year from | 2021correct |
| Model year to | 2026correct |
| Sales region | bothcorrect |
