Volvo A25E

Series: Volvo Articulated Dump Truck

Source: https://commons.wikimedia.org/w/index.php?curid=17799200

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the A25E, Volvo offers a model from the Volvo Articulated Dump Truck series. The engine delivers 304.2 hp (223 kW), has 6 cylinders, with a displacement of 9,406.2 cm³. Torque is 1,700.2 Nm. Rated speed is 2,100 rpm. The wheelbase measures 4,172.7 mm. Ground clearance is 658.4 mm. Top speed is 52.9 km/h. The tank holds 401.3 litres. The gearbox has 6 forward gears. There are also 2 reverse gears. Maximum torque is reached at 1,200 rpm. The hydraulic tank holds 174.1 litres. The cooling system holds 115.1 litres. The oil fill is 40.1 litres. The electrical system runs on 24 V. The engine fitted is the D9B ABE3. Tyre size: 23.5R25. The Volvo Articulated Dump Truck series covers 23 models. Rated output within it ranges from 258.5 to 482.6 hp; the A25E sits in the lower part of that range with 304.2 hp. Its immediate neighbours are the A25C 6x6 below it with 258.5 hp and the A25D above it with 314.3 hp. 5366 Volvo models across 29 series are on record. The model is listed under Mining equipment. 23 verified figures from 1 source are on file.

Technical data

Engine

Engine model	D9B ABE3correct
Power	304.2 hp (223 kW)correct
Rated speed	2,100 rpmcorrect
Torque	1,700.2correct
Speed at max. torque	1,200 rpmcorrect
Cylinders	6correct
Displacement	9,406.2 cm³correct
Aspiration	Turbocharged and Intercooledcorrect
Coolant capacity	115.1 lcorrect
Engine oil capacity	40.1 lcorrect

Dimensions and weights

Length	10,219.9correct
Width	2,697.5correct
Height	3,260 mmcorrect
Wheelbase	4,172.7correct
Ground clearance	658.4correct

Drivetrain and chassis

Gearbox type	Volvo PowerTronic planetary transmissioncorrect
Forward gears	6correct
Reverse gears	2correct
Tyre size	23, 5R25correct
Top speed	52.9 km/hcorrect

Working data

Hydraulic oil capacity	174.1 lcorrect
Fuel tank capacity	401.3 lcorrect

Other data

System voltage	24 Vcorrect

Frequently asked questions

How much power does the Volvo A25E have?

The Volvo A25E delivers 304 hp.

What engine does the Volvo A25E have?

6 cylinders, 9,406 cm³ displacement.

How fast does the Volvo A25E go?

Top speed is 52.9 km/h.

What are the dimensions of the Volvo A25E?

10,220 mm × 2,698 mm × 3,260 mm.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
