Valmet 504

Built: 1982–1985 · Series: 04 er-Baureihe

More machines from model year 1982

Source: https://www.tractordata.com/farm-tractors/001/9/6/1961-valme

The Valmet 504 belongs to the 04er series. Production: 1982–1985. The engine delivers 50 hp (36.8 kW), has 3 cylinders, with a displacement of 2,685 cm³. Torque is 170 Nm. Rated speed is 2,300 rpm. The machine is 3,617 mm long, 1,890 mm wide and 2,500 mm high. The unladen weight is 2,690 kg. The wheelbase measures 2,112 mm. Ground clearance is 400 mm. Top speed is 30 km/h. The tank holds 65 litres. Transmission: 6 V/2 R. The engine is water-cooled. Tyres: front 7.50-16 ASF, rear 14.9-30 AS. The fuel is diesel. The bore measures 108 mm. The stroke is 114 mm. The compression ratio is 17:1. Maximum torque is reached at 1,300 rpm. Construction: frame construction. The gearbox offers 6 forward gears. There are also 2 reverse gears. Injection pressure is 201 bar. The linkage is category II. The 04 er-Baureihe series covers 3 models. Rated output within it ranges from 50 to 66 hp; the 504 sits at the bottom of that range with 50 hp. Its immediate neighbours are the 604 / 604-4 above it with 61 hp. Unladen weight within it ranges from 2,690 to 2,820 kg; here the 504 sits at the bottom of that range with 2,690 kg. 414 Valmet models across 21 series are on record.

Valmet 04 range: collective page of Finnish tractors 504 and 604 (also as Turbo) from Suolahti, three-cylinder diesels, 37 to 49 kW, 1980s

The 04 range from Valmet, dating from the 1980s, comprises the models 504 and 604 in the register, the latter also available in a turbocharged Turbo version; they were built at the Finnish plant in Suolahti. The model numbers rank the range by power class, and the -4 suffix denotes the four-wheel-drive variant. With the optional turbocharging on the 604, the range relied on comparatively modern technology for its time. That extra output made a real difference when pulling heavier implements.

Read on 3 more paragraphs

The register lists 3 versions with 36.8 to 48.5 kW from three-cylinder diesel engines of 2,685 to 3,298 cm³, unladen weights of 2,690 to 2,820 kg, a length of 3,617 mm, widths of 1,890 to 1,930 mm and heights of 2,500 to 2,554 mm; torque ranges from 170 to 235 Nm at a rated speed of 2,300 rpm.

Turbocharging the more powerful 604 was, for a Finnish tractor of the period, an early step toward more power from relatively small displacement, helping it keep pace with rivals' larger six-cylinder models; the 04 range covered the mid power segment on Nordic farms.

When buying used, on the Turbo version particularly the condition of the turbocharger and charge-air ducting matters, and on all models the injection pump, cooling, gearbox and clutch; spare parts are available through today's Valtra network and independent farm-machinery dealers.

Sources: SpecCodex register, model data: Valmet 04er

Technical data

Engine

Fuel	dieselcorrect
Power	50 hp (36.8 kW)correct
Rated speed	2,300 rpmcorrect
Torque	170 Nmcorrect
Speed at max. torque	1,300 rpmcorrect
Cylinders	3correct
Displacement	2,685 cm³correct
Bore	108 mmcorrect
Stroke	114 mmcorrect
Compression ratio	17correct
Injection pressure	201 barcorrect
Cooling	water-cooledcorrect

Dimensions and weights

Length	3,617 mmcorrect
Width	1,890 mmcorrect
Height	2,500 mmcorrect
Wheelbase	2,112 mmcorrect
Ground clearance	400 mmcorrect
Unladen weight	2,690 kgcorrect

Drivetrain and chassis

Drive	rear-wheel drivecorrect
Gearbox	6 V/2 Rcorrect
Forward gears	6correct
Reverse gears	2correct
Front tyres	7.50-16 ASFcorrect
Rear tyres	14.9-30 AScorrect
Top speed	30 km/hcorrect

Working data

Fuel tank capacity	65 lcorrect

Origin and approval

Construction	frame constructioncorrect

Other data

Linkage category	Cat IIcorrect

Where this model stands

Power-to-weight ratio: 13.7 kW/t (37 kW / 2.7 t)

Power class: Universal (40–100 hp)

Stronger than 34% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Valmet 504 have?

The Valmet 504 delivers 50 hp.

How much does the Valmet 504 weigh?

The unladen weight is 2,690 kg.

What engine does the Valmet 504 have?

3 cylinders, 2,685 cm³ displacement, Diesel.

How fast does the Valmet 504 go?

Top speed is 30 km/h.

What are the dimensions of the Valmet 504?

3,617 mm × 1,890 mm × 2,500 mm.

When was the Valmet 504 built?

Production years: 1982–1985.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
Shift the gearbox cold and warm — jumps only show up at temperature.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
