Ursus C-325
Built: 1959–1963 · Series: 300 er-Baureihe
More machines from model year 1959
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The Ursus 300 range – Polish twin-cylinder tractors C-325 and C-328 from Warsaw: 18.4 to 20.6 kW (25 to 28 hp), 1,654 kg unladen weight
In Ursus's type logic the 300 range follows the early C models and here brings together the closely related C-325 and C-328 – two twin-cylinder diesels from the Polish maker Ursus near Warsaw, which differ mainly in output and track width but otherwise share largely the same basic design. Both types targeted smaller and medium farms that needed a simple, robust general-purpose tractor.
Read on 3 more paragraphs
The register lists 2 versions with 18.4 to 20.6 kW (25 to 28 hp) from twin-cylinder engines of 1,810 to 1,961 cm³, torque of 93 to 100 Nm, an unladen weight of 1,654 kg, a length of 3,030 mm, widths of 1,250 to 1,680 mm, a height of 1,500 mm and rated speeds of 2,000 to 2,200 rpm.
The 300s were among the common smaller tractors of Polish farming and served as general-purpose tractors for smaller and medium holdings, where manoeuvrability and low fuel consumption mattered more than high drawbar pull; within the Ursus range they thus sat a step below the larger, more powerful lines.
On used examples, the condition of the injection pump, the tightness of the cylinder head and cooling system, the state of clutch and gearbox, and rust on mudguards and bonnet all count; spare parts run through Polish farm-machinery dealers and the used market, and aftermarket reproductions for wear parts, since factory-original stock is largely exhausted after so many decades.
Sources: SpecCodex register, model data: Ursus 300er-Baureihe, Ursus (manufacturer)
Technical data
Engine
| Engine | Ursus S-312correct |
|---|---|
| Fuel | dieselcorrect |
| Power | 25 hp (18.4 kW)correct |
| Rated speed | 2,000 rpmcorrect |
| Torque | 93 Nmcorrect |
| Cylinders | 2correct |
| Displacement | 1,810 cm³correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 3,030 mmcorrect |
|---|---|
| Width | 1,250 mmcorrect |
| Height | 1,500 mmcorrect |
| Wheelbase | 1,842 mmcorrect |
| Ground clearance | 400 mmcorrect |
| Unladen weight | 1,654 kgcorrect |
Drivetrain and chassis
| Drive | rear-wheel drivecorrect |
|---|---|
| Gearbox | 6 V/2 Rcorrect |
| Forward gears | 6correct |
| Reverse gears | 2correct |
| Front tyres | 6.00-16 ASFcorrect |
| Rear tyres | 10-28 AScorrect |
| Top speed | 20 km/hcorrect |
Working data
| Fuel tank capacity | 35 lcorrect |
|---|
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|---|
| Units built | 26,282correct |
Other data
| Linkage category | Cat IIcorrect |
|---|
Where this model stands
Power-to-weight ratio: 11.1 kW/t (18 kW / 1.7 t)
Power class: Compact (< 40 hp)
Stronger than 12% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Ursus C-325 have?
The Ursus C-325 delivers 25 hp.
How much does the Ursus C-325 weigh?
The unladen weight is 1,654 kg.
What engine does the Ursus C-325 have?
2 cylinders, 1,810 cm³ displacement, Diesel.
How fast does the Ursus C-325 go?
Top speed is 20 km/h.
What are the dimensions of the Ursus C-325?
3,030 mm × 1,250 mm × 1,500 mm.
When was the Ursus C-325 built?
Production years: 1959–1963.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
