Terex TX760B

Series: Terex Loader Backhoe

Source: https://www.terex.com/rough-terrain-cranes/en/product/rough-

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Terex Loader Backhoe series from Terex includes the TX760B. The engine delivers 93.3 hp (64.1 kW), with a displacement of 4,408.1 cm³. Rated speed is 2,200 rpm. The wheelbase measures 2,100.1 mm. Ground clearance is 387.1 mm. The tank holds 130.2 litres. The gearbox has 4 forward gears. There are also 4 reverse gears. Maximum torque is reached at 1,400 rpm. The pump delivers 142.3 l/min. The hydraulic tank holds 143.1 litres. Working pressure is 224.1 bar. The cooling system holds 16.3 litres. The electrical system runs on 12 V. The engine fitted is the 1004C-44TL. The Terex Loader Backhoe series covers 14 models. Rated output within it ranges from 75 to 101.4 hp; the TX760B sits in the upper part of that range with 93.3 hp. Its immediate neighbours are the TX750 below it with 76 hp and the TLB840 above it with 95.1 hp. 377 Terex models across 29 series are on record. The model is listed under Wheel loaders. 18 verified figures from 1 source are on file.

Technical data

Engine

Engine model1004C-44TLcorrect
Power93.3 hp (64.1 kW)correct
Rated speed2,200 rpmcorrect
Speed at max. torque1,400 rpmcorrect
Displacement4,408.1 cm³correct
Aspirationturbochargedcorrect
Coolant capacity16.3 lcorrect

Dimensions and weights

Wheelbase2,100.1correct
Ground clearance387.1correct

Drivetrain and chassis

Gearbox typeCarraro power shuttlecorrect
Forward gears4correct
Reverse gears4correct
System voltage12 Vcorrect

Working data

Pump flow142.3 l/mincorrect
Hydraulic oil capacity143.1 lcorrect
Hydraulic pressure224.1correct
Fuel tank capacity130.2 lcorrect

Frequently asked questions

How much power does the Terex TX760B have?

The Terex TX760B delivers 93.3 hp.

What engine does the Terex TX760B have?

4,408 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
