Start › Backhoe loaders › Terex › TLB840

Terex TLB840

Series: Terex Loader Backhoe

Source: https://www.baupool.com/details/Siebanlagen--mobil/Terex-Fin

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Terex Loader Backhoe series from Terex includes the TLB840. The engine delivers 95.1 hp (65.7 kW), has 4 cylinders, with a displacement of 4,401.6 cm³. The engine comes from Deutz. Rated speed is 2,200 rpm. The wheelbase measures 2,133.6 mm. Ground clearance is 408.4 mm. The tank holds 116.6 litres. The gearbox has 4 forward gears. There are also 4 reverse gears. Maximum torque is reached at 1,400 rpm. The pump delivers 79.5 l/min. The hydraulic tank holds 92.4 litres. Working pressure is 249.9 bar. The cooling system holds 16.3 litres. The electrical system runs on 12 V. The Terex Loader Backhoe series covers 14 models. Rated output within it ranges from 75 to 101.4 hp; the TLB840 sits in the upper part of that range with 95.1 hp. Its immediate neighbours are the TX760B below it with 93.3 hp and the 860 Elite above it with 101.4 hp. 377 Terex models across 29 series are on record. The model is listed under Wheel loaders. 17 verified figures from 1 source are on file.

Technical data

Engine

Engine makeDeutzcorrect
Power95.1 hp (65.7 kW)correct
Rated speed2,200 rpmcorrect
Speed at max. torque1,400 rpmcorrect
Cylinders4correct
Displacement4,401.6 cm³correct
Coolant capacity16.3 lcorrect

Dimensions and weights

Wheelbase2,133.6correct
Ground clearance408.4correct

Drivetrain and chassis

Forward gears4correct
Reverse gears4correct
System voltage12 Vcorrect

Working data

Pump flow79.5 l/mincorrect
Hydraulic oil capacity92.4 lcorrect
Hydraulic pressure249.9correct
Fuel tank capacity116.6 lcorrect

Frequently asked questions

How much power does the Terex TLB840 have?

The Terex TLB840 delivers 95.1 hp.

What engine does the Terex TLB840 have?

4 cylinders, 4,402 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 17 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
