Terex TX750

The TX750 from Terex is part of the Terex Loader Backhoe series. The engine delivers 76 hp (51.5 kW), with a displacement of 4,200 cm³. The engine comes from PERKINS. Rated speed is 2,200 rpm. The wheelbase measures 2,100.1 mm. Ground clearance is 371.9 mm. The tank holds 120.4 litres. The gearbox has 4 forward gears. There are also 4 reverse gears. Maximum torque is reached at 1,400 rpm. The pump delivers 79.5 l/min. The hydraulic tank holds 90.1 litres. Working pressure is 224.1 bar. The cooling system holds 16.3 litres. The electrical system runs on 12 V. The engine fitted is the Model 1 1004-40 T. The Terex Loader Backhoe series covers 14 models. Rated output within it ranges from 75 to 101.4 hp; the TX750 sits at the bottom of that range with 76 hp. Its immediate neighbours are the TLB840R below it with 75 hp and the 820 above it with 93.3 hp. 377 Terex models across 29 series are on record. The model is listed under Wheel loaders. 17 verified figures from 1 source are on file.
