Terex 860SX

Series: Terex Loader Backhoe

Source: https://www.kleinanzeigen.de/s-anzeige/radlader-terex-schaef

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The 860SX from Terex is part of the Terex Loader Backhoe series. The engine delivers 101.4 hp (70.1 kW), with a displacement of 4,408.1 cm³. Rated speed is 2,200 rpm. The wheelbase measures 2,130.6 mm. Ground clearance is 454.2 mm. The tank holds 130.2 litres. The gearbox has 4 forward gears. There are also 4 reverse gears. Maximum torque is reached at 1,400 rpm. The pump delivers 160.1 l/min. The hydraulic tank holds 143.1 litres. Working pressure is 224.1 bar. The cooling system holds 16.3 litres. The electrical system runs on 12 V. The engine fitted is the 1104C-44T. The Terex Loader Backhoe series covers 14 models. Rated output within it ranges from 75 to 101.4 hp; the 860SX sits at the top of that range with 101.4 hp. Its immediate neighbours are the TLB840 below it with 95.1 hp. 377 Terex models across 29 series are on record. The model is listed under Wheel loaders. 17 verified figures from 1 source are on file.

Technical data

Engine

Engine model1104C-44Tcorrect
Power101.4 hp (70.1 kW)correct
Rated speed2,200 rpmcorrect
Speed at max. torque1,400 rpmcorrect
Displacement4,408.1 cm³correct
Coolant capacity16.3 lcorrect

Dimensions and weights

Wheelbase2,130.6correct
Ground clearance454.2correct

Drivetrain and chassis

Gearbox typeSyncrho shuttle gearboxcorrect
Forward gears4correct
Reverse gears4correct
System voltage12 Vcorrect

Working data

Pump flow160.1 l/mincorrect
Hydraulic oil capacity143.1 lcorrect
Hydraulic pressure224.1correct
Fuel tank capacity130.2 lcorrect

Frequently asked questions

How much power does the Terex 860SX have?

The Terex 860SX delivers 101 hp.

What engine does the Terex 860SX have?

4,408 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
