Terex GS4096RT
Series: Terex Scissor Lift
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Terex scissor lifts GS1530 to GS5390RT – Genie lifts under the Terex name: the number as platform height in feet and width in inches, RT for rough terrain, DC for electric rough-terrain lifts, 1.2 to 7.5 t
The scissor lifts under the Terex name are Genie designs: since Terex took over the aerial-platform maker Genie of Redmond near Seattle in 2002, the lifts have run worldwide under the Genie brand, but in some markets and rental fleets also with a Terex badge – the GS types in the register are identical to the Genie GS. The type logic follows the American convention: GS stands for Genie Scissor, the first digits give the platform height in feet, the last the platform width in inches – a GS1930 is 19 ft high and 30 in wide, a GS3246 32 ft and 46 in, a GS5390RT 53 ft and 90 in. The suffixes name drive and duty: the models without suffix are the electric indoor lifts, RT the diesel rough-terrain lifts with all-wheel drive, DC the electric rough-terrain lifts with battery drive, AV an equipment variant.
Read on 3 more paragraphs
The register lists 21 versions with service weights from 1,168 to 7,515 kg, lengths from 1,830 to 4,880 mm and widths from 760 to 2,362 mm; the rough-terrain lifts deliver 18.5 to 55.9 kW with Kubota diesels and Ford DSG-423 petrol engines, the indoor lifts run on battery.
The GS1930 – 760 mm wide, 5.8 m platform height – is, together with the JLG 1930ES, the most-hired work platform in the world; the GS5390RT with 16 m platform height is the site lift for façades and hall roofs.
On used lifts, operating hours, battery condition on electric models, play in scissor pins and rails, hydraulic tightness, the function of tilt and overload sensors and a valid periodic inspection count; parts run through the Genie network.
Sources: Kennwerte der Modelle Terex Scherenbühnen, Genie (Terex, Hersteller)
Technical data
Engine
| Engine model | Kubota D-1105 Tier 4f dieselcorrect |
|---|---|
| Fuel | Gas/LPGcorrect |
| Power | 25.1 hp (18.5 kW)correct |
Dimensions and weights
| Length | 3,120.1correct |
|---|---|
| Width | 1,752.6correct |
| Wheelbase | 2,292.1correct |
| Ground clearance | 241.3correct |
| Unladen weight | 4,647 kgcorrect |
Drivetrain and chassis
| Tyre size | 12 x 26correct |
|---|---|
| Top speed | 5.6 km/hcorrect |
Working data
| Hydraulic oil capacity | 68.1 lcorrect |
|---|---|
| Fuel tank capacity | 38.2 lcorrect |
More machines with this engine (Kubota D-1105 Tier 4f diesel, 2)
Where this model stands
Power-to-weight ratio: 4 kW/t (18 kW / 4.6 t)
Stronger than 19% of the aerial work platforms in the register — out of 205 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Terex GS4096RT have?
The Terex GS4096RT delivers 25.1 hp.
How much does the Terex GS4096RT weigh?
The unladen weight is 4,647 kg.
How fast does the Terex GS4096RT go?
Top speed is 5.6 km/h.
What are the dimensions of the Terex GS4096RT?
3,120 mm × 1,753 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 13 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
