Takeuchi TB135

Series: Takeuchi Mini Excavator

Source: https://commons.wikimedia.org/w/index.php?curid=117241850 u

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the TB135, Takeuchi offers a model from the Takeuchi Mini Excavator series. The engine delivers 28.2 hp (20.7 kW), has 3 cylinders, with a displacement of 1,638.7 cm³. Torque is 107.1 Nm. Rated speed is 2,300 rpm. The unladen weight is 3,552.1 kg. Ground clearance is 295.7 mm. The tank holds 51.1 litres. Maximum torque is reached at 1,400 rpm. The pump delivers 75 l/min. The hydraulic tank holds 85.2 litres. Working pressure is 206.8 bar. The cooling system holds 5.7 litres. The oil fill is 4.9 litres. The electrical system runs on 12 V. The engine fitted is the 3TNV88-QTB. The Takeuchi Mini Excavator series covers 15 models. Rated output within it ranges from 8.1 to 33.5 hp; the TB135 sits in the upper part of that range with 28.2 hp. Its immediate neighbours are the TB025 below it with 26.4 hp and the TB235 above it with 30.2 hp. 48 Takeuchi models across 8 series are on record. The model is listed under Excavators & compaction. 18 verified figures from 1 source are on file.

Technical data

Engine

Engine model3TNV88-QTBcorrect
Power28.2 hp (20.7 kW)correct
Rated speed2,300 rpmcorrect
Torque107.1correct
Speed at max. torque1,400 rpmcorrect
Cylinders3correct
Displacement1,638.7 cm³correct
Coolant capacity5.7 lcorrect
Engine oil capacity4.9 lcorrect

Dimensions and weights

Ground clearance295.7correct
Unladen weight3,552.1 kgcorrect

Drivetrain and chassis

System voltage12 Vcorrect

Working data

Pump flow75 l/mincorrect
Hydraulic oil capacity85.2 lcorrect
Hydraulic pressure206.8 barcorrect
Fuel tank capacity51.1 lcorrect

Other data

Height2,438.4correct

Where this model stands

Power-to-weight ratio: 5.8 kW/t (21 kW / 3.6 t)

Stronger than 63% of the mini excavators in the register — out of 400 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Takeuchi TB135 have?

The Takeuchi TB135 delivers 28.2 hp.

How much does the Takeuchi TB135 weigh?

The unladen weight is 3,552 kg.

What engine does the Takeuchi TB135 have?

3 cylinders, 1,639 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
